Description
Product Overview
The IS200TREGH1BDC Trip Primary Gas Termination Card from General Electric belongs to the Mark VIe Series. This compact PCB weighs 0.22 kg and measures 2.1 x 18.6 x 26.3 cm, offering reliable integration into turbine control systems. Engineers value its twelve transformers, forty-eight silver terminals, and surge protection components that ensure stable performance in demanding environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IS200TREGH1BDC |
| Module Type |
Trip Primary Gas Termination Card |
| Manufacturer |
GE |
| Product Range |
Mark VIe |
| Condition |
Brand New |
| Weight |
0.22 kg |
| Dimensions |
2.1 x 18.6 x 26.3 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
| Transformers |
12 square-shaped, silver wiring |
| Terminals |
48 silver, two sets of 24 |
| Surge Protection |
Red MOVs around board edges |
| Jumper Ports |
JH1 (3), J2 (12), J1 (2) |
| Components |
Diodes, resistors, capacitors, ICs |
Functional Description
The IS200TREGH1BDC board enhances turbine control systems by combining transformers, terminals, and surge protection. Twelve square-shaped transformers, enclosed in transparent plastic, provide voltage details and part numbers. Two black terminal blocks house forty-eight silver terminals, ensuring secure electrical connections.
Engineers benefit from integrated diodes, resistors, capacitors, transistors, and ICs that reinforce voltage protection. Red MOVs positioned around the edges safeguard against surges, while jumper ports JH1, J2, and J1 expand connectivity with seventeen terminals. This design ensures reliable operation within GE Mark VIe legacy systems.
Applications and Compatibility
The IS200TREGH1BDC Trip Primary Gas Termination Card suits turbine control, excitation systems, and industrial automation requiring stable electrical termination. It integrates seamlessly with GE Speedtronic Mark VIe assemblies, ensuring compatibility across diverse environments. Engineers deploy it in power generation plants, heavy industry, and automation networks where secure connections and surge protection are critical.
