Description
Product Overview
The IS200TDBSH2A Discrete Simplex Card from General Electric belongs to the Mark VIe Series. This compact PCB weighs 0.22 kg and measures 2.1 x 18.6 x 26.3 cm, making it suitable for turbine control and industrial automation systems. Engineers value its robust construction, precise signal handling, and reliable performance in demanding environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IS200TDBSH2A |
| Module Type |
Discrete Simplex Card |
| Manufacturer |
GE |
| Product Range |
Mark VIe |
| Condition |
Brand New |
| Weight |
0.22 kg |
| Dimensions |
2.1 x 18.6 x 26.3 cm |
| HS Code |
8537101190 |
| Minimum Order Quantity |
1 |
| Origin |
USA |
| System |
DCS |
| Status |
Active |
| Communication Service |
Ethernet router |
| Power Supply |
+24V DC |
| Operating Temperature |
-40°C to +70°C |
| Terminal Blocks |
TB1 and TB2, 48 terminals each |
| Connector Port |
Mid-sized, multiple female pins |
| Components |
Diodes, resistors, capacitors, ICs |
Functional Description
The IS200TDBSH2A terminal board facilitates input and output signal connections within GE’s Mark VIe control systems. Two large terminal blocks, TB1 and TB2, provide a total of forty-eight terminals for secure wiring. A mid-sized connector port on the opposite edge offers versatile interfacing options.
Engineers benefit from its durable PCB design, which includes diodes, resistors, capacitors, and integrated circuits for voltage protection. Operating on a +24V DC supply, the IS200TDBSH2A supports a wide temperature range from -40°C to +70°C, ensuring reliable performance in harsh industrial conditions.
Applications and Compatibility
The IS200TDBSH2A Discrete Simplex Card suits turbine control, excitation systems, and industrial automation requiring precise signal termination. It integrates seamlessly with GE Speedtronic Mark VIe assemblies, ensuring compatibility across diverse environments. Engineers deploy it in power generation plants, heavy industry, and automation networks where dependable wiring and robust performance are critical.
