Description
Product Overview
The GE IS200TBCIS2CCD Discrete Input Terminal Board from the Mark VIe Series provides high-performance input handling for turbine control systems. With 32 optically isolated channels supporting 24–125 VDC signals, it ensures rapid response and reliable monitoring in critical power generation environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IS200TBCIS2CCD |
| Manufacturer |
General Electric |
| Module Type |
Discrete Input Terminal Board |
| Dimensions |
2 × 18.6 × 12.7 cm |
| Weight |
0.12 kg |
| System |
DCS |
| Communication Service |
Ethernet router |
| Input Channels |
32 optically isolated |
| Signal Range |
24–125 VDC |
| Response Time |
≤10 ms |
| Isolation Protection |
1500 V AC |
| Power Requirement |
+5 V DC |
| Current Consumption |
5–15 mA per channel |
| Indicators |
LED status for each channel |
| Output Signal |
4–20 mA, ±0.25% accuracy |
| Temperature Range |
-40°C to +70°C operation |
| Measurement Range |
-200°C to +600°C |
| Protection Rating |
IP67 dust and moisture resistance |
| Certifications |
CE, UL, IEC 61131-2 |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Functional Highlights
The IS200TBCIS2CCD delivers precise monitoring with LED indicators for each channel. Its passive design requires only +5 VDC, while IP67 protection ensures durability against dust and moisture. The board’s stable 4–20 mA output signal supports accurate temperature measurement across extreme ranges.
Design and Performance
General Electric engineered the IS200TBCIS2CCD with compact dimensions and lightweight construction for easy installation. Its optically isolated inputs and 1500 V AC protection enhance system safety, while energy-efficient operation ensures long-term reliability in continuous use.
Applications and Compatibility
The IS200TBCIS2CCD Discrete Input Terminal Board suits turbine control systems in aviation, marine, and energy industries. It integrates seamlessly with GE Mark VIe platforms, supporting legacy Speedtronic technology while meeting CE, UL, and IEC standards for global deployment.
