Description

Overview

The IS200EPDMG1B Exciter Power Distribution Module from GE’s EX2100 Excitation Control system delivers filtered and regulated power to control, I/O, and protection boards. It mounts directly to the IS200EPBP backplane and receives primary 125 Vdc power from the station battery, with optional 120 Vac backup inputs.

Technical Specifications

Specification	Detail
Manufacturer	GE
Model Number	IS200EPDMG1B
Product Series	EX2100 Excitation Control System
Function	Power distribution and protection
Voltage Input	125 Vdc / 120 Vac
Voltage Output	28 Vdc
Current	2 A
Dimensions	16 cm × 10 cm × 6 cm
Weight	0.3 kg
Terminal Block	24-point
Plug Connectors	12
Fuses	18
Switches	7 (rated 125 Vdc, 6 A)
LED Indicators	10
Grounding	4 mounting holes
Connector Rating	600 V ac/dc
Terminal Rating	300 V, 10 A per pin
Jumper	Adjustable BJS for ground isolation

Specifications

• Dimensions: 16 cm × 10 cm × 6 cm
• Brand: GE

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
