GE IS200EISBH1AAC Mark VI EX2100 Exciter ISBus Board

The GE IS200EISBH1AAC, also cataloged as the IS200EISBH1AAC Exciter ISBus Board, operates as a dedicated hardware component for fiber-optic communication and excitation feedback signal transfer within GE Mark VI and EX2100 excitation control systems. It interfaces exciter modules with DSPX controllers through ISBus channels.

Hardware Specifications

Parameter	Specification
Model	IS200EISBH1AAC
Brand	GE (General Electric)
Origin	United States
Weight	0.5 kg
Dimensions	116 mm x 224 mm x 152 mm
Operating Temp	-30 deg C to +65 deg C
Series	Mark VI Speedtronic / EX2100 Excitation Control
Product Type	Exciter ISBus Communication Boards
Board Type	Exciter ISBus Communication Board
Mounting	Single-slot 3U-high VME rack module
Communication Interface	Fiber optic connectors, 6 channels
Backplane Interface	Single connector to DSPX controller
Managed Signals	Generator field voltage/current, exciter voltage/current, ground detect input/output
Indicators	6 LEDs for voltage/current and ground detect status
Humidity Range	5%-95% non-condensing
PCB Protection	Conformal coating
Energy Dissipation	Residual energy discharged within 2 seconds after power-off

Profinet / EtherNet-IP Deterministic Network Integration

The IS200EISBH1AAC provides fiber-optic ISBus communication between excitation control modules and controller assemblies in GE Mark VI and EX2100 systems. The optical interface transfers generator field voltage/current feedback, exciter measurement signals, and ground detection information with electrical isolation from connected control circuits.

The board operates as a communication layer beneath the DSPX controller, using a VME rack connection and fiber channels for signal exchange. The six-channel optical interface supports coordinated communication between exciter modules and redundant controller configurations.

The conformal-coated PCB construction provides protection against moisture, dust, and chemical contaminants. The module design supports deterministic signal transfer within the excitation control backplane architecture.

Frequently Asked Questions

Q: What communication medium is used by the IS200EISBH1AAC?
A: The board uses fiber-optic connectors with six communication channels for ISBus signal transfer between excitation modules and controllers.

Q: Which signals are processed through the Exciter ISBus Board?
A: The module manages generator field voltage/current feedback, exciter voltage/current signals, and ground detection input/output signals.

Q: What rack interface does this board use?
A: The IS200EISBH1AAC is installed in a single-slot 3U-high VME rack position with a backplane connection to the DSPX controller.

Field Installation Guidelines

Install the IS200EISBH1AAC in the designated GE Mark VI or EX2100 VME rack slot and confirm correct mechanical alignment before inserting the board.

Inspect fiber-optic connectors for contamination, scratches, or improper coupling before connection. Maintain fiber cable bend radius requirements and route optical cables away from mechanical stress points.

Verify rack grounding, power isolation conditions, and controller interface compatibility before system energization. Maintain separation between communication wiring and high-current excitation conductors to reduce electromagnetic interference.

Before operation, confirm LED status indications, fiber communication links, and signal assignments between the EISB board and connected DSPX controller hardware.
