Description

Overview

The IS200EACFG1B Exciter AC Feedback Board from GE’s EX2100 Excitation Control system delivers precise voltage and current measurements for exciter applications. It captures three-phase AC supply data using onboard transformers and supports two flux/air core coil inputs for current sensing.

Technical Specifications

Specification	Detail
Manufacturer	GE
Model Number	IS200EACFG1B
Product Series	EX2100 Excitation Control System
Function	AC voltage and current feedback
Voltage	24 Vdc
Current	1 A
Dimensions	18 cm × 12 cm × 5 cm
Weight	0.3 kg
Voltage Range	Up to 480 V rms (EACFG1)
Connector Type	DB9 (3 outputs)
Coil Inputs	2 flux/air core terminals
Cable Length Support	Up to 90 m
Noise Suppression	High-frequency filtering
Mounting Location	Exciter auxiliary cabinet

Specifications

• Dimensions: 18 cm × 12 cm × 5 cm
• Brand: GE

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
