Description
Product Overview
The GE IS200DAMAG1BCB Gate Drive Amplifier/Interface Board is engineered for low-voltage 620 frame drive systems within the Mark VI Speedtronic platform. It connects directly to both legs of the IGBT module, typically CM1000HA-28 H Powerrex, and interfaces with the Bridge Personality Interface Board (BPIA) via two vertical connectors.
This board ensures reliable gate drive control and signal amplification. Its PCB design emphasizes conductivity, insulation, and mechanical stability, making it ideal for industrial environments involving gas or steam turbine control.
Technical Specifications
| Specification |
Details |
| Manufacturer |
GE |
| Part Number |
IS200DAMAG1BCB |
| Ordering Code |
IS200DAMAG1B |
| Product Series |
Mark VI |
| Description |
Gate Drive Amplifier/Interface Board |
| Power Rating |
620 frame |
| Voltage |
24 Vdc |
| Dimensions |
18 cm × 12 cm × 3 cm |
| Weight |
0.5 kg |
| Connectors |
12-pin and 6-pin vertical |
| IGBT Compatibility |
CM1000HA-28 H Powerrex |
| Origin |
USA |
Key Features
-
Connects to upper and lower phase legs of IGBT modules
-
Interfaces with BPIA using dual vertical connectors
-
Supports gate drive control and signal amplification
-
PCB design resists vibration, humidity, and thermal stress
-
Compact 18×12×3 cm size fits standard drive enclosures
-
Lightweight 0.5 kg board simplifies installation and replacement
-
Designed for maintainability and cost-effective manufacturing
Applications & Compatibility
The IS200DAMAG1BCB board is ideal for drive systems requiring precise gate control and robust signal interfacing. It supports Mark VI Speedtronic platforms and integrates seamlessly with IGBT modules and BPIA boards.
Compatible with:
-
GE Mark VI low-voltage drive systems
-
620 frame drives for gas and steam turbines
-
IGBT modules like CM1000HA-28 H Powerrex
-
Industrial setups requiring high-performance gate drive amplification
