GE IS200BPPBH2BMD Analog I/O Processor Board

Configured for analog signal acquisition and output processing in GE Mark VI Speedtronic Turbine Control Systems, the GE IS200BPPBH2BMD (IS200BPPB Analog I/O Processor Board) provides direct physical/electrical execution for sensor interfacing, channel processing, and analog data conversion. The board handles differential and single-ended input signals with 16-bit ADC processing and isolated analog outputs.

Hardware Specifications

Parameter	Specification
Model	IS200BPPBH2BMD
Brand	GE
Origin	United States
Weight	0.48 kg
Dimensions	3.0 cm x 16.0 cm x 26.0 cm
Operating Temp	-30 to +65 deg C
Power Consumption	5 VDC from host system
Product Type	Analog I/O Processor Board
System Platform	GE Mark VI Speedtronic Turbine Control System
Analog Inputs	16 differential or 32 single-ended channels
Analog Outputs	8 isolated analog channels
ADC Resolution	16-bit
DAC Resolution	14-bit
Processor	32-bit RISC microcontroller
Communication Interface	Dual 64-pin backplane connectors
Isolation Rating	2500 Vrms
Coating	Conformal coating revision H2BMD

Profinet / EtherNet-IP Deterministic Networks and I/O Processing

The IS200BPPBH2BMD operates as an analog processing node within the Mark VI control architecture, managing channel conversion, signal conditioning, and data exchange through the turbine control backplane. The board supports I/O density scaling by providing multiple analog channels in a single rack position while maintaining deterministic acquisition timing.

Firmware flash compatibility and board revision control are maintained through the Mark VI hardware configuration environment. Diagnostic routines monitor channel status, conversion operation, and internal processing conditions for system-level fault reporting.

Frequently Asked Questions

Q: What analog input configurations are supported by the IS200BPPBH2BMD?
A: The board supports 16 differential analog input channels or 32 single-ended analog input channels depending on system configuration.

Q: How is the module connected to the Mark VI control system?
A: The board interfaces with the host control rack through dual 64-pin backplane connectors.

Q: Does the IS200BPPBH2BMD provide electrical isolation?
A: The board provides isolated analog outputs and an isolation rating of 2500 Vrms for signal separation.

Field Installation Guidelines

Confirm system power removal before installation or replacement. Use ESD protection procedures when handling the board assembly. Insert the board into the designated Mark VI rack position until both backplane connectors are fully engaged.

Secure front-panel hardware to maintain mechanical retention and chassis grounding. Route analog signal wiring separately from high-current switching conductors. Connect cable shields according to cabinet grounding practices to reduce electrical noise coupling.

Configure differential or single-ended input modes through the Mark VI software configuration tools before returning the control system to operation.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
