Description
Overview
The IS200BICLH1AED bridge interface card from General Electric is a high-performance PCB designed for EX2100 drive assemblies. It facilitates communication between the main control board and the Bridge Personality Interface Board, supporting fault monitoring, temperature tracking, and PWM speed control.
This compact module measures 20.2×11.7×3 cm and weighs 0.22 kg. The IS200BICLH1AED includes dual fault string inputs, four RTD sensor channels, and a fan speed PWM output for dynamic cooling control.
Technical Specifications
| Specification |
Details |
| Model Number |
IS200BICLH1AED |
| Module Type |
Gas Turbine Card |
| Manufacturer |
General Electric (GE) |
| Series |
EX2100 / Mark VI |
| System |
DCS |
| Dimensions |
20.2 × 11.7 × 3 cm |
| Weight |
0.22 kg |
| Fault Inputs |
Dual Fault String |
| RTD Inputs |
4 Channels (Single/Dual Mode) |
| PWM Output |
Fan Speed Control (Open Collector) |
| Memory Device |
1024-bit Serial ID |
| Board Type |
Bridge Interface PCB |
| Communication |
Ethernet Router |
| HS Code |
8537101190 |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Status |
Active |
Features & Performance
-
The IS200BICLH1AED supports ambient temperature monitoring via RTD sensors.
-
Its PWM fan output adjusts cooling dynamically based on system demand.
-
Dual fault string inputs ensure safe shutdown during signal disruption.
-
The onboard memory stores board identification and revision data for traceability.
Applications & Compatibility
The IS200BICLH1AED integrates into GE EX2100 and Mark VI turbine control systems. It suits industrial drive applications requiring precise fault detection, temperature control, and fan speed modulation.
Compatible with Innovation Series drive assemblies, the IS200BICLH1AED enhances system reliability and thermal management in gas turbine environments.
