GE IS200ACLEH1BAA Application Control Layer Module

The GE IS200ACLEH1BAA, also cataloged as the IS200ACLEH1BAA Application Control Layer PCB, operates as a dedicated hardware component for deterministic turbine sequencing and control processing within the GE Speedtronic Mark VI control platform.

Suffix Breakdown & Model Matrix

The IS200ACLEH1BAA is identified as a fixed Mark VI Application Control Layer module. The provided documentation defines the functional revision and configuration suffix without a separate modular ordering matrix.

Parameter	Specification
Model	IS200ACLEH1BAA
Brand	GE
Origin	United States
Hardware Type	Application Control Layer (ACLE) PCB
System Platform	Speedtronic Mark VI
Processor	Embedded DSP/ARM processor
Memory	Onboard RAM and Flash storage
Communication Interfaces	Ethernet, IONet, Modbus
Isolation	2.5 kV RMS field-to-logic
Weight	Approx. 0.5-0.7 kg
Dimensions	Rack-mount PCB form factor
Operating Temp	-40 deg C to +70 deg C
Power Consumption	Not specified; 28 VDC nominal power input
Environmental Protection	Conformal coating for dust, humidity, and salt fog environments

Hardware Specifications

Parameter	Specification
Model	IS200ACLEH1BAA
Brand	GE
Origin	United States
Functional Role	Application processing, sequencing, and turbine control communication
Input Power	28 VDC nominal
Processor Architecture	Embedded DSP/ARM processing platform
Communication Protocols	Ethernet, IONet, Modbus
Signal Processing	Real-time control execution and data handling
Isolation Voltage	2.5 kV RMS field-to-logic
PCB Construction	Rack-mounted industrial control board
Weight	0.5 kg
Operating Temp	-40 deg C to +70 deg C
Power Consumption	Not specified; nominal 28 VDC supply

Industrial Control Processing and Network Compatibility

The GE Mark VI platform uses distributed control hardware with dedicated communication paths between controller modules, I/O assemblies, and application processing layers. The IS200ACLEH1BAA provides processor-based execution for turbine application logic and communicates through Ethernet, IONet, and Modbus interfaces.

The module supports firmware-based control functions, where flash memory compatibility and application software revision alignment are required during controller configuration. Network timing depends on the Mark VI system architecture, communication configuration, and connected I/O modules.

Frequently Asked Questions

Q: What communication interfaces are available on the IS200ACLEH1BAA?
A: The module supports Ethernet, IONet, and Modbus communication interfaces as specified for the Mark VI control platform.

Q: What power input is required for this module?
A: The IS200ACLEH1BAA operates from a 28 VDC nominal power input according to the supplied technical data.

Q: Does the module provide electrical isolation?
A: The module includes 2.5 kV RMS field-to-logic isolation for separation between external signals and internal control electronics.

Field Installation Guidelines

Install the IS200ACLEH1BAA in the designated Mark VI rack position according to the system hardware configuration documentation.

Verify that the supply voltage wiring is correctly terminated before energizing the module. Communication cables should be routed separately from high-current power conductors to reduce electromagnetic interference.

Use proper grounding practices for rack assemblies and cable shields. Confirm connector seating, backplane engagement, and firmware compatibility before placing the module into service.
