Description
Product Description
The GE IC698CHS117 is a 17-slot I/O backplane designed for the PACSystems RX7i series, serving as the central framework for system integration. It provides the physical and electrical connections required for CPUs, power supplies, communication modules, and I/O units, distributing power and communication signals reliably across the rack. This backplane is engineered for industrial environments, offering durable construction and compatibility with all RX7i modules.
Its standard dimensions allow for easy panel or cabinet mounting, while optional fan assemblies support thermal management in dense configurations. The backplane operates at 5–12 V DC and delivers up to 350 W of power, with a maximum current rating of 60 A at 5 V and 12 A at 12 V, ensuring stable operation for multiple modules simultaneously.
Technical Specifications
| Specification |
Details |
| Model |
IC698CHS117 |
| Product Series |
PACSystems RX7i |
| Module Type |
I/O Rack / Backplane |
| Slots |
17 module slots |
| Compatibility |
RX7i CPUs, power supplies, I/O, communication modules |
| Operating Voltage |
5–12 V DC |
| Power Supply |
350 W |
| Current Rating |
60 A @ 5 V DC / 12 A @ 12 V DC |
| Dimensions |
11.2 × 19.0 × 7.5 inches (H × W × D) |
| Mounting |
Panel or rear-wall cabinet mounting |
| Fan Assembly |
Optional |
| Weight |
13.0 lbs |
Key Features
-
17-slot capacity supports complex RX7i system configurations
-
Backplane bus distributes power and communication signals to all modules
-
Compatible with CPUs, power supplies, I/O, and communication modules
-
Industrial-grade durability for reliable performance in harsh environments
-
Optional fan assembly for enhanced thermal management
-
Standard RX7i dimensions for easy integration into cabinets or panels
Application Scenarios
-
Large-scale automation systems requiring multiple I/O modules
-
Process industries with distributed control requirements
-
Factory automation setups where RX7i controllers manage complex machinery
-
System integration projects needing modular expansion capability
FAQ
Q: How many modules can be installed on this rack?
A: Up to 17 modules, including CPUs, I/O, power, and communication units.
Q: What is the maximum power capacity?
A: 350 W, with current limits of 60 A at 5 V and 12 A at 12 V.
Q: Can this backplane be mounted in a standard cabinet?
A: Yes, it supports both panel and rear-wall mounting.
Q: Is this compatible with newer PACSystems RX3i modules?
A: No, it is specific to RX7i series modules; RX3i racks are required for newer modules.
