Description
Overview
The IC697PWR720C is a robust power supply module designed for the Series 90‑70 PLC family. It delivers stable, regulated DC power to CPUs, I/O, and communication modules in large-scale automation systems. Engineered for high reliability, it supports dual-rack operation and ensures uninterrupted performance in demanding industrial environments.
Technical Specifications
-
Model/Part Number: IC697PWR720C
-
Brand: GE Fanuc (Emerson Automation)
-
Series: Series 90‑70 PLC
-
Module Type: High-Capacity Power Supply
-
Input Voltage: 90–132 VAC or 180–264 VAC (auto-sensing)
-
Input Frequency: 47–63 Hz
-
Output Ratings:
-
+5 VDC @ up to 100 A
-
+12 VDC @ up to 15 A
-
–12 VDC @ up to 2 A
-
Total Power Capacity: 700 W continuous
-
Voltage Regulation: Maintains stable 5 V, 12 V, and –12 V outputs under load
-
Rack Output Current: +5 VDC @ 18 A; +12 VDC @ 2 A; –12 VDC @ 1 A
-
Backplane Current Draw: 50 mA from 5 V bus
-
Cooling: Internal fan with forced air circulation
-
Indicators: Front panel LEDs for power status and fault conditions
-
Protection Features: Overvoltage, overcurrent, and thermal shutdown
-
Isolation: 1500 VAC field-to-ground for 1 minute
-
Mounting: Designed for dedicated power supply slot in standard IC697 racks
-
Dual Rack Operation: Supported (requires optional expansion cable IC697CBL700)
-
VME Compatibility: Supports VME standard C.1
-
Weight: 0.9 kg
Key Features
-
High-current capacity for extensive Series 90‑70 systems
-
Multiple regulated outputs for flexible module support
-
Built-in diagnostics via LED indicators for rapid troubleshooting
-
Robust protection against electrical faults and overheating
-
Universal AC input simplifies installation in global applications
-
Supports dual-rack operation and logic expansion
Applications
-
Large-scale PLC-controlled process lines
-
Multi-rack systems requiring high current and stability
-
Critical industrial operations needing redundant or dual power feeds
FAQ
Q: Can this module operate in dual-rack systems?
A: Yes, dual-rack operation is supported with optional expansion cable IC697CBL700.
Q: What is the maximum total output power?
A: Continuous 700 W across all outputs.
Q: Does it support automatic voltage sensing?
A: Yes, it auto-senses between 90–132 VAC and 180–264 VAC input ranges.
Q: What protections are built into the module?
A: Overvoltage, overcurrent, and thermal shutdown are included.
