Product Description
The GE IC697CPX935 is a high-capacity central processing unit designed for the GE Fanuc Series 90-70 PLC family. It serves as the core controller, executing complex automation programs, managing extensive I/O networks, and coordinating communications across large-scale industrial systems.
Equipped with a 32-bit CPU and 2 MB of user memory (expandable), IC697CPX935 supports multitasking for simultaneous process control and logic execution. It provides serial and LAN connectivity for integration with supervisory systems, enabling reliable communication and data exchange in demanding automation environments. Integrated diagnostics, including LED indicators and self-test routines, facilitate quick troubleshooting and system monitoring.
This module is ideal for legacy installations requiring a robust, reliable PLC CPU capable of managing thousands of I/O points and executing high-speed program logic.
Technical Specifications
| Specification |
Details |
| Model |
IC697CPX935 |
| Series |
GE Fanuc Series 90-70 PLC |
| Module Type |
CPU Module |
| Processor |
32-bit microprocessor |
| User Memory |
2 MB RAM, expandable |
| Instruction Execution |
High-speed program processing |
| I/O Capacity |
Supports thousands of I/O points via expansion racks |
| Communication Ports |
Serial (RS-232/RS-485) and LAN interfaces depending on configuration |
| Diagnostics |
Built-in self-test, fault reporting, LED indicators |
| Compatibility |
Series 90-70 PLC systems |
| Power Requirements |
5 VDC, 3.1 A typical |
| Scan Time |
Approximately 5.9 ms per typical program cycle |
| Boolean Execution Speed |
0.4 µs per instruction |
| Temperature Range |
0–50°C |
Key Features
-
High-memory capacity for complex automation programs
-
Supports multitasking for concurrent processes
-
Multiple communication interfaces for network integration
-
Scalable I/O with expansion rack support
-
Built-in diagnostics for enhanced system reliability
-
Compatible with existing Series 90-70 PLC installations
Application Scenarios
-
Process industries: Central control of chemical, oil & gas, or power plants
-
Manufacturing: Supervisory control for multiple production lines
-
Utility systems: Large-scale automation in water treatment and energy distribution
-
Research & testing: High-speed logic execution for experimental setups
FAQ
Q: Can this CPU module handle large I/O networks?
A: Yes, IC697CPX935 supports thousands of I/O points via compatible expansion racks.
Q: What memory capacity is available?
A: It comes with 2 MB of user RAM, expandable with Series 90-70 memory modules.
Q: Which communication interfaces are supported?
A: Serial (RS-232, RS-485) and LAN ports depending on configuration.
Q: Is this module compatible with PACSystems RX3i CPUs?
A: No, it is designed specifically for Series 90-70 PLC systems. RX3i CPUs offer modern Ethernet-based communication and higher performance.
