Product Description
The IC697ACC724 is a dedicated rack-mounted fan assembly engineered for GE Fanuc Series 90‑70 PLC systems. Designed to maintain optimal airflow in high-density racks containing CPUs, power supplies, and I/O modules, this fan assembly prevents overheating, prolongs component lifespan, and ensures stable operation under harsh industrial conditions.
The unit mounts directly to the bottom of the PLC rack and channels cool air from below while exhausting warm air through module slots. Depending on revision, the assembly contains two or three integrated fans to optimize airflow, complemented by a polyurethane foam filter to reduce dust accumulation. Its compact, rugged construction supports continuous operation even in elevated ambient temperatures.
Technical Specifications
| Parameter |
Specification |
| Manufacturer |
GE Fanuc / Emerson |
| Model |
IC697ACC724 |
| Product Type |
Rack-Mounted Cooling Fan |
| PLC Compatibility |
Series 90‑70 |
| Operating Voltage |
230–240 VAC |
| Power Consumption |
16–17 W |
| Line Current |
0.09–0.10 A |
| Locked Rotor Current |
0.12–0.14 A |
| Cooling Method |
Forced convection airflow |
| Nominal Airflow |
71 CFM |
| Number of Fans |
2 (standard), 3 (optional revision) |
| Filter Type |
Polyurethane foam, 30 PPI |
| Operating Temperature |
–28 °C to +70 °C |
| Mounting Position |
Bottom of PLC rack |
| Housing |
Industrial-grade with integrated power leads |
| Retainer & Guard |
UL94V‑0 plastic |
| Dimensions |
331 × 150 × 60 mm |
| Weight |
3.00 lbs |
Key Features & Advantages
-
Maintains consistent airflow to prevent thermal stress in high-density PLC racks
-
Dual-fan redundancy ensures cooling continues if one fan fails
-
Optional three-fan configuration for enhanced performance in high-heat applications
-
Foam filter minimizes dust buildup and prolongs fan life
-
Direct rack integration simplifies installation—no external brackets required
-
Supports industrial environments with elevated ambient temperatures
-
Low power consumption relative to cooling capacity
Applications
-
Cooling of Series 90‑70 PLC CPU racks and I/O modules
-
Industrial control cabinets with high-density electronics
-
Environments requiring reliable, continuous airflow under elevated temperatures
-
Hazardous or dusty industrial locations requiring dust filtration
FAQ
Q: Can the IC697ACC724 operate with a failed fan?
A: Yes, the dual-fan design provides redundancy to maintain airflow if one fan stops.
Q: Is this compatible with all Series 90‑70 racks?
A: The assembly is designed for standard Series 90‑70 PLC racks and mounts directly to the bottom.
Q: Does it include a filter?
A: Yes, a polyurethane foam filter is included to reduce dust accumulation.
