Description
Product Description
The GE Fanuc IC695SPF550 is a high-speed fiber optic module designed for the PACSystems RX3i family, providing robust, noise-immune communication across extended industrial sites. Engineered for high-bandwidth data transfer, this module ensures reliable connectivity between RX3i racks and devices, supporting demanding automation environments where signal integrity and speed are critical.
Equipped with single-mode or multi-mode fiber interfaces, the IC695SPF550 offers long-distance transmission, immunity to EMI/RFI, and LED-based diagnostics for easy monitoring of link status. Its compact, rack-compatible design allows flexible deployment within RX3i systems.
Technical Specifications
| Specification |
Details |
| Model |
IC695SPF550 |
| Product Type |
Fiber Optic Communication Module |
| System |
PACSystems RX3i |
| Communication Medium |
Fiber optic (single-mode/multi-mode) |
| Data Rate |
Up to 1 Gbps |
| Distance |
Up to several kilometers depending on fiber type |
| Number of Ports |
8 fiber optic transceiver ports |
| I/O Capacity |
32 points |
| Installation |
Standard RX3i rack slot |
| Diagnostics |
LED indicators for link status and activity |
| Power Requirements |
3.3 V @ 1.9 A, 5 V @ 1.1 A |
| Connector Type |
SFP cage / RJ45 interface |
| Temperature Rating |
0°C to 60°C |
| Noise Immunity |
Immune to EMI/RFI interference |
| Weight |
3.0 lbs |
Key Features
-
High-Speed Fiber Connectivity: Supports fast data transfer up to 1 Gbps.
-
Long-Distance Communication: Fiber optic medium enables kilometers of reliable transmission.
-
Noise Immunity: Resistant to EMI and RFI, ideal for harsh electrical environments.
-
Multiple Ports: Eight transceiver ports for flexible network design.
-
Integrated Diagnostics: LED indicators for easy monitoring of link activity.
-
Flexible Installation: Fits standard RX3i rack slots for easy integration.
Applications
-
Linking RX3i racks across large industrial facilities
-
High-bandwidth data transfer in noise-prone environments
-
Distributed automation systems requiring fiber optic connectivity
-
Communication backbone for fast, deterministic industrial networks
FAQ
Q: What fiber types does the IC695SPF550 support?
A: Supports both single-mode and multi-mode fibers depending on configuration.
Q: How many ports are available on this module?
A: The module has 8 fiber optic transceiver ports.
Q: What is the maximum distance for communication?
A: Distance varies by fiber type and installation, typically up to several kilometers.
Q: Can it handle high EMI environments?
A: Yes, fiber optic medium provides immunity to EMI and RFI.
