Product Description
The GE IC695SPF002 is a compact Small Form-Factor Pluggable (SFP) scanner module engineered for PACSystems RX3i PLCs. It provides high-speed communication for distributed I/O systems using fiber-optic and Ethernet connections. Designed for both local and remote I/O networks, the module supports multi-mode fiber transmission up to 2 km, dual RJ-45 ports, and dual SFP slots for flexible deployment. SD card support allows configuration storage and data logging, while LED indicators provide clear operational status. Its compact footprint enables convenient installation in RX3i racks, supporting robust networking in complex industrial environments.
Key Features
-
High-speed 100 Mbps data communication for remote I/O connectivity.
-
Multi-mode fiber support with transmission distances up to 2 km.
-
Dual RJ-45 ports and SFP cages for versatile networking options.
-
LED indicators for operational and activity monitoring.
-
SD card slot for configuration storage and system data backup.
-
Compact design fits easily into RX3i rack-mounted PLC systems.
Technical Specifications
| Parameter |
Specification |
| Manufacturer |
GE Fanuc / Emerson |
| Part Number |
IC695SPF002 |
| Product Type |
RX3i SFP Scanner Module |
| Communication Speed |
100 Mbps |
| Media Type |
Multi-Mode Fiber (MMF) |
| Maximum Transmission Distance |
2 km |
| Connectors |
2 × RJ-45 ports, 2 × SFP cages |
| SD Card Support |
Yes |
| LED Indicators |
Status and activity |
| Operating Voltage |
3.3–5 VDC |
| Operating Temperature |
0–60 °C |
| Dimensions |
180 × 165 × 215 mm |
| Weight |
0.06 kg |
Applications
-
Remote I/O expansion for RX3i PLCs.
-
Industrial networks requiring fiber-optic connectivity.
-
Oil & gas, power generation, and renewable energy plants.
-
Food & beverage processing and manufacturing facilities.
-
Distributed control systems with high-speed communication needs.
FAQ
Q: What type of fiber does IC695SPF002 support?
A: It supports multi-mode fiber (MMF) for distances up to 2 km.
Q: How many network ports does the module provide?
A: It includes two RJ-45 Ethernet ports and two SFP cages for fiber-optic modules.
Q: Can I store configuration data on this module?
A: Yes, it has an SD card slot for configuration and data storage.
Q: Is the module compatible with all RX3i PLCs?
A: It is designed specifically for PACSystems RX3i PLCs and compatible modules.
