Product Description
The GE Fanuc IC695RMX128 is a high-speed Redundancy Memory Xchange (RMX) module designed for the PACSystems RX3i family. It enables hot-standby CPU redundancy and deterministic reflective memory networking, ensuring mission-critical systems maintain continuous operation with minimal downtime. This module supports large-scale reflective memory networks, providing synchronized data across all nodes for reliable industrial control.
Equipped with 128 MB of reflective memory and fiber-optic networking, the IC695RMX128 can serve as either a dedicated redundancy link between CPUs or as a general node in a distributed memory network. It supports up to 256 nodes, allowing scalable deployment in complex automation architectures. Hot-swap capability and advanced diagnostics simplify maintenance and fault detection, making it ideal for high-availability environments.
Technical Specifications
| Specification |
Details |
| Model |
IC695RMX128 |
| Product Type |
Redundancy Memory Xchange (RMX) Module |
| System Compatibility |
PACSystems RX3i |
| Memory Capacity |
128 MB reflective memory |
| Network Type |
Fiber-optic reflective memory network |
| Maximum Nodes |
256 nodes in reflective memory configuration |
| Data Sharing |
Deterministic, automatic updates across all nodes |
| Redundancy Role |
High-speed link for hot-standby CPU systems |
| Compatibility |
Functionally identical to IC695CMX128 when used as standard node |
| Supported Protocols |
Compatible with 5565 family reflective memory devices |
| Hot-Swap Support |
Yes |
| Diagnostics |
Advanced monitoring and fault detection for redundancy |
| Installation |
Fits RX3i main rack or distributed network nodes |
| Environmental Temperature |
0 °C to 60 °C (optional extended range available) |
| Weight |
1.2 kg |
Key Features
-
High-Speed Reflective Memory: Ensures all connected nodes receive synchronized data instantly.
-
CPU Redundancy Support: Provides a dedicated link between primary and backup CPUs in hot-standby configurations.
-
Scalable Network: Supports up to 256 nodes for large, distributed control systems.
-
Deterministic Data Sharing: Guarantees consistent data updates across controllers and devices.
-
Hot-Swap Capability: Reduces downtime during maintenance or replacement.
-
Advanced Diagnostics: Monitors system health and detects faults proactively.
-
Flexible Operation: Can function as a dedicated redundancy module or a general reflective memory node.
Applications
-
High-availability PACSystems RX3i control systems
-
Industrial process control requiring deterministic data exchange
-
Hot-standby CPU redundancy setups
-
Large-scale distributed automation networks
FAQ
Q: Can IC695RMX128 function in non-redundancy networks?
A: Yes, it can operate as a standard reflective memory node compatible with IC695CMX128 devices.
Q: How many nodes can this module support?
A: Up to 256 nodes in a reflective memory network.
Q: Does it support hot-swapping?
A: Yes, hot-swap capability allows replacement without shutting down the system.
Q: Is it compatible with older PACSystems RX3i modules?
A: Yes, it is fully compatible with RX3i hot-standby and distributed reflective memory configurations.
