Description

Overview

The IC695CPU310 is a high-performance CPU module for the PACSystems RX3i series, designed to handle demanding industrial automation tasks. Featuring a 300 MHz RISC processor, 10 MB battery-backed RAM, and 10 MB non-volatile Flash memory, it delivers rapid execution of Boolean logic and complex programs. Advanced communications, dual backplane support, and robust industrial design ensure reliability, scalability, and minimal downtime in machine, process, robotics, and material handling applications.

Technical Specifications

• Model/Part Number: IC695CPU310

• Brand: GE Fanuc (Emerson)

• Series: PACSystems RX3i

• Type: Central Processing Unit (CPU Module)

• Processor: 300 MHz RISC core (Intel Celeron-M class)

• Memory:

• 10 MB battery-backed RAM

• 10 MB non-volatile Flash user memory

• Program Blocks: Up to 512 blocks, 128 KB max per block

• Execution Speed: 0.195 ms per 1,000 Boolean instructions

• Floating Point Support: Yes

• I/O Capacity:

• 32K discrete points (%I/%Q)

• 32K analog words (%AI/%AQ)

• Embedded Communications:

• 2 isolated serial ports (RS-232/RS-485)

• 10/100 Mbps Ethernet interface (supports up to 16 concurrent TCP sessions)

• Supported Protocols: Modbus RTU Slave, SNP, OPC UA, HMI/MES connectivity

• Time-of-Day Clock Accuracy: Max drift 2 seconds/day

• Elapsed Time Clock Accuracy: 0.01% max

• Switchover Time: As low as 1 logic scan (~3.133 ms)

• Backplane Support: Dual bus – RX3i PCI and 90-30-style serial

• Power Requirements: +3.3 VDC 1.25 A nominal, +5 VDC 1.0 A nominal

• Environmental Ratings:

• Operating temperature: 0–60 °C

• Vibration resistance: 2 g

• Shock resistance: 15 g

• Isolation: 1500 VAC field-to-ground for 1 minute

• Certifications: CE, UL

• MTBF: ≥230,000 hours

Key Features

• High-speed 300 MHz processing for robotics, packaging, and complex automation

• Large memory capacity for extensive programs and data retention

• Dual serial ports and Ethernet reduce need for external gateways

• Conformal coating resists sulfur, salt mist, and harsh industrial environments

• Remote firmware upgrade and rollback capability for minimal downtime

Applications

• Real-time control of machinery, robotics, and material handling systems

• Complex process automation requiring fast Boolean execution

• Integration with HMI, MES, and industrial communication networks

• Scalable system expansion for RX3i I/O modules

FAQ

Q: What type of programs can IC695CPU310 execute?
A: Supports Ladder Diagram, Structured Text, Function Block Diagram, and C programming.

Q: How fast is Boolean execution?
A: Typical speed is 0.195 ms per 1,000 Boolean instructions.

Q: Can it handle both PCI and serial backplanes?
A: Yes, dual backplane support includes RX3i PCI and 90-30-style serial backplanes.

Q: Is the module suitable for harsh industrial environments?
A: Yes, conformal coating protects against sulfur, salt mist, vibration, and shock.

Specifications

• Dimensions: 33 × 10 × 5 cm
• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
