Product Description
The GE IC695CBL002 is a dedicated connection cable designed for PACSystems RX3i controllers, enabling secure linkage between the CPU and the Energy Pack module. This cable plays a critical role in maintaining system continuity by supporting backup power transfer and communication integrity during power interruptions.
Engineered for industrial environments, it features a shielded construction and keyed connector to ensure proper installation and consistent signal transmission. The 1-meter length is optimized for control cabinet layouts, reducing excess wiring while maintaining installation flexibility.
Technical Specifications
| Specification |
Details |
| Model |
IC695CBL002 |
| Manufacturer |
GE Fanuc / Emerson |
| Product Line |
PACSystems RX3i |
| Type |
CPU to Energy Pack Connection Cable |
| Cable Length |
1 meter (36 inches) |
| Connector |
7-pin keyed connector |
| Wiring Configuration |
Straight-through |
| Termination |
Integrated termination resistor |
| Compatibility |
RX3i CPU and Energy Pack modules |
| Voltage Range |
24 VDC, 125 VDC, 120/240 VAC (system dependent) |
| Shielding |
Industrial-grade shielded cable |
| Operating Temperature |
0°C to +60°C |
| Weight |
0.45 kg |
Key Features
-
Dedicated RX3i Interface: Designed specifically for CPU-to-Energy Pack connectivity.
-
Secure Connection Design: 7-pin keyed connector prevents incorrect installation.
-
Signal Integrity: Shielded cable minimizes electrical noise and interference.
-
Integrated Termination: Built-in resistor improves communication stability.
-
Optimized Length: 1-meter cable supports clean and efficient cabinet wiring.
-
Industrial Durability: Suitable for continuous operation in control environments.
Typical Applications
-
PACSystems RX3i control cabinets requiring Energy Pack backup integration
-
Power continuity solutions in industrial automation systems
-
Critical process control systems where CPU backup power is essential
-
Manufacturing lines requiring reliable controller operation during outages
FAQ
Q: What is the purpose of the IC695CBL002 cable?
A: The IC695CBL002 connects an RX3i CPU to its Energy Pack, enabling backup power support and maintaining system data integrity.
Q: Can this cable be used with other GE PLC series?
A: No, it is specifically designed for PACSystems RX3i and is not interchangeable with other PLC families.
Q: Does the cable include termination components?
A: Yes, it includes an integrated termination resistor to ensure stable communication.
Q: Is shielding necessary for this application?
A: Yes, shielding helps protect against electromagnetic interference in industrial environments, ensuring reliable operation.
