Product Description
The GE Fanuc IC695ACC400 is a supercapacitor-based Energy Pack designed for PACSystems RX3i CPUs, providing reliable, battery-free backup to preserve CPU memory during power interruptions. By eliminating the need for conventional batteries, this module ensures long-term operational reliability while minimizing maintenance requirements.
Engineered for RX3i CPUs such as the IC695CPE330, the IC695ACC400 delivers sufficient energy to safely transfer user programs and data to non-volatile memory during power loss. The module installs directly onto the CPU via a dedicated connector and features LED indicators for charging status, fault detection, and capacitance health. With a rapid recharge time of under 15 minutes and a lifespan of over 10 years at standard operating temperatures, it is a durable, eco-friendly solution for protecting critical automation logic.
Technical Specifications
| Specification |
Details |
| Model |
IC695ACC400 |
| Product Type |
CPU Energy Pack |
| System |
PACSystems RX3i |
| Compatible CPUs |
IC695CPE305, IC695CPE310, IC695CPE330 |
| Backup Technology |
Supercapacitor-based (battery-free) |
| Backup Function |
Maintains CPU memory and logic during power loss |
| Recharge Time |
<15 minutes to full charge |
| Retention Period |
Maintains memory contents for months without external power |
| Installation |
Directly mounts to CPU module (dedicated connector) |
| Mounting Location |
Left side of CPU module |
| Operating Temperature |
0–60 °C (32–140 °F) |
| Weight |
0.69 lbs |
| Cable |
IC695CBL001, 0.91 m (3 ft) |
| Connector Type |
Samtec IPD1-04-D-K |
| Indicators |
Charging, Charged, Fault, Low Capacitance |
| Operating Life |
10+ years at 0–50 °C; 4.5 years at 60 °C |
| Voltage Rating |
300 VAC cable rating |
| Compliance |
EU RoHS Directive 2011/65/EU |
| Maintenance |
No battery replacement required |
Key Features
-
Battery-Free Design: Uses supercapacitors instead of batteries for memory backup.
-
Fast Recharge: Rapidly restores full backup capacity after power restoration.
-
Long Retention: Safeguards CPU programs and data during extended outages.
-
Easy Installation: Connects directly to RX3i CPUs without additional hardware.
-
LED Diagnostics: Visual indicators for charge status, faults, and capacitance health.
Advantages
-
Enhanced Reliability: More consistent performance compared to battery-based backup systems.
-
Low Maintenance: No periodic battery replacement required.
-
Eco-Friendly: Eliminates battery disposal concerns.
-
High System Availability: Protects critical programs against data loss during power events.
Applications
-
RX3i CPU memory protection during power outages.
-
Systems requiring battery-free, long-term data retention.
-
Industrial environments where maintenance reduction and reliability are critical.
FAQ
Q: Which CPUs are compatible with the IC695ACC400?
A: Compatible with IC695CPE305, IC695CPE310, and IC695CPE330 CPUs.
Q: How long does it take to recharge?
A: Typically less than 15 minutes to fully charge after power is restored.
Q: Does it require battery replacement?
A: No, the module uses supercapacitors and requires no battery maintenance.
Q: How long will it retain CPU data?
A: Memory contents are maintained for months without external power.
