Product Description
The GE IC694TBB032 is a high-density terminal block designed for PACSystems RX3i PLCs, providing a secure and organized wiring interface for connecting field devices to discrete and analog I/O modules. With 32 screw-type terminals, it ensures reliable signal termination while supporting compact panel or DIN-rail mounting. This terminal block is compatible with high-density RX3i I/O modules such as IC694MDL753 and IC694MDL754, offering flexible integration into complex control systems. Industrial-grade construction guarantees durability in demanding environments.
Key Features
-
32 screw-type terminals for secure and reliable field wiring.
-
Compatible with high-density RX3i discrete and analog I/O modules.
-
Compact box-style design for efficient panel space utilization.
-
Screw clamp connections prevent loose wiring and ensure long-term reliability.
-
Supports #14–26 AWG solid or stranded wires with recommended 7 lb-in torque.
-
Can be mounted on panels or DIN rails for flexible installation.
-
Designed for industrial environments with 0–60 °C operating temperature range.
Technical Specifications
| Parameter |
Specification |
| Manufacturer |
GE Fanuc / Emerson |
| Part Number |
IC694TBB032 |
| Product Type |
High-Density Terminal Block Module |
| Terminal Points |
32 screw-type terminals |
| Connection Type |
Screw clamp |
| Supported Modules |
RX3i high-density I/O modules (e.g., IC694MDL753, IC694MDL754) |
| Wire Gauge Supported |
#14–26 AWG (solid or stranded) |
| Wire Strip Length |
0.310 in (7.87 mm) |
| Tightening Torque |
7 lb-in |
| Mounting Style |
Panel or DIN-rail mount |
| Dimensions |
100 × 70 × 30 mm |
| Weight |
0.31 lbs |
| Operating Temperature |
0–60 °C |
| Storage Temperature |
-40–85 °C |
| Humidity Range |
5–95% RH, non-condensing |
Applications
-
Connecting field devices to high-density discrete or analog I/O modules.
-
Manufacturing process control and monitoring systems.
-
Energy and utility control panels requiring compact, reliable wiring solutions.
-
Transportation and infrastructure automation systems.
FAQ
Q: Can this terminal block handle both solid and stranded wires?
A: Yes, it supports #14–26 AWG solid or stranded wires.
Q: Is it compatible with all RX3i I/O modules?
A: It is compatible with high-density RX3i modules such as IC694MDL753 and IC694MDL754.
Q: How should the screw terminals be maintained?
A: Periodic tightening is recommended to prevent signal loss over time.
Q: What mounting options are available?
A: The IC694TBB032 can be mounted on panels or DIN rails for flexible installation.
