Description
Product Overview
The GE IC694MDL754 Discrete Output Module from the PACSystem RX3i platform delivers high-density digital output control. With 32 channels organized into two isolated groups, it supports positive logic wiring and ensures reliable operation in industrial automation systems.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC694MDL754 |
| Manufacturer |
GE |
| Module Type |
Discrete Output Module |
| Dimensions |
3.6 × 13.4 × 13.7 cm |
| Weight |
0.25 kg |
| System |
DCS |
| Communication Service |
Ethernet router |
| Output Channels |
32 (two groups of 16) |
| Voltage Range |
10.2–30.0 VDC |
| Nominal Voltage |
12/24 VDC |
| Current Capacity |
0.75 A per channel |
| Response Time |
0.5 ms |
| Inrush Current |
3 A for 10 ms |
| Backplane Current Draw |
300 mA at 5 V |
| Protections |
Short-circuit, overcurrent, overtemperature with auto-recovery |
| Compatibility |
RX3i CPUs firmware v2.90+ |
| Terminal Blocks |
Box-style or spring-style supported |
| Status Indicators |
Individual channel LEDs |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Functional Highlights
The IC694MDL754 integrates advanced protections with auto-recovery, ensuring safe and continuous operation. Its fast 0.5 ms response time and LED indicators provide precise monitoring, while isolated channel groups enhance reliability in control systems.
Design and Performance
GE engineered the IC694MDL754 with compact dimensions and lightweight construction for easy installation. Its high channel density and robust safeguards make it a dependable choice for industrial automation requiring efficient discrete output control.
Applications and Compatibility
The IC694MDL754 Discrete Output Module suits PACSystem RX3i platforms in manufacturing, energy, and process automation. It integrates seamlessly with RX3i CPUs and supports flexible installation options, making it ideal for systems requiring precise digital output management.
