Product Description
The GE IC693CMM302 is an Ethernet communications coprocessor designed for the Series 90-30 PLC family. This single-slot module enables Series 90-30 PLCs to communicate over Ethernet TCP/IP networks, supporting multiple protocols such as SRTP and Modbus TCP/IP. With integrated diagnostic LEDs and support for up to 31 bus devices, it provides reliable connectivity and monitoring for plant-wide automation systems.
Engineered for legacy GE PLC systems, the IC693CMM302 integrates seamlessly into standard Series 90-30 racks, offering robust backplane isolation and low power consumption (<300 mA at 5 VDC). Its compact design allows flexible slot placement (any slot except the CPU), making it suitable for both new and retrofit installations.
Technical Specifications
| Specification |
Details |
| Part Number |
IC693CMM302 |
| Product Series |
GE Fanuc Series 90-30 |
| Module Type |
Ethernet Communications Coprocessor Module (CMM) |
| Network Interface |
Ethernet TCP/IP |
| Connector Type |
RJ-45 |
| Supported Protocols |
SRTP, Modbus TCP/IP, standard TCP/IP |
| Data Rate |
10/100 Mbps |
| Bus Devices Supported |
Up to 31 devices |
| Slot Width |
Single slot |
| Compatible Host |
Series 90-30 PLC |
| Slot Placement |
Any slot except CPU slot |
| Mounting |
CPU, Expansion, and Remote Baseplates |
| Global Data Length |
128 bytes (Transmit and Receive) |
| Supported Registers |
%G, %I, %Q, %AI, %AQ, %R |
| Diagnostics |
OK LED and COMM LED |
| Weight |
0.88 lbs |
| Backplane Current Draw |
<300 mA at 5 VDC |
Key Features
-
Ethernet connectivity for Series 90-30 PLC systems
-
Supports multiple protocols: SRTP, Modbus TCP/IP, standard TCP/IP
-
Built-in diagnostic LEDs for status and activity monitoring
-
Single-slot module with flexible placement in Series 90-30 racks
-
Handles up to 31 bus devices with 128-byte global data transfers
-
Low power consumption and robust backplane isolation
Application Scenarios
-
Factory automation: Integrate Series 90-30 PLCs with plant Ethernet networks
-
Process control: Connect PLCs to Modbus TCP/IP devices or SCADA systems
-
Legacy system support: Bridge older Series 90-30 PLCs to modern network infrastructure
-
Data monitoring: Interface with industrial PCs or supervisory systems for global data exchange
FAQ
Q: Can this module support modern Ethernet standards like PROFINET?
A: No, the IC693CMM302 is designed for legacy Series 90-30 systems and supports SRTP and Modbus TCP/IP but not PROFINET.
Q: How many devices can I connect on the bus?
A: Up to 31 bus devices can be supported at standard baud rates.
Q: Where can this module be installed?
A: Any slot in a Series 90-30 rack except the CPU slot.
Q: What diagnostic features are available?
A: Two LEDs indicate module status (OK) and communication activity (COMM).
