Product Description
The IC693CBL302 is a 15‑meter I/O bus expansion cable engineered for the GE Fanuc Series 90‑30 PLC system. Specifically designed as the final link in a daisy‑chain configuration, it connects the CPU baseplate to the last expansion or remote baseplate, ensuring reliable communication across long distances.
Featuring an integrated 100‑ohm termination resistor, the IC693CBL302 eliminates the need for external terminators, maintaining signal integrity at the end of the bus. Its continuous EMI shielding and rugged industrial construction provide high noise immunity and stable data transmission in electrically harsh environments. This makes it ideal for distributed control systems and complex automation setups.
Technical Specifications
| Parameter |
Specification |
| Model |
IC693CBL302 |
| Manufacturer |
GE Fanuc / Emerson |
| Product Line |
Series 90‑30 |
| Product Type |
I/O Bus Expansion Cable |
| Cable Length |
15 meters (50 ft) |
| Usage |
End-of-chain cable for final expansion link |
| Weight |
3.75 lbs |
| Conductor Gauge |
24 AWG stranded |
| Voltage Rating |
Up to 300 V AC/DC |
| Current Capacity |
1 A max |
| Impedance |
100 Ω nominal |
| Data Rate |
Up to 10 Mbps |
| Insulation Resistance |
>1000 MΩ @ 500 VDC |
| Connectors |
Male 25‑pin D‑Sub on both ends |
| Termination |
Built-in 100‑ohm resistor |
| Shielding |
Continuous EMI shielding (>90% noise reduction) |
| Operating Temperature |
–20 °C to 70 °C |
| Storage Temperature |
–30 °C to 80 °C |
| Humidity |
Up to 95% non-condensing |
| Vibration Resistance |
5–500 Hz, 5G |
| Hot-Swap |
Not supported (power off required) |
Key Features & Advantages
-
15 m cable designed for long-distance bus expansion up to 213 m total system run
-
Built-in termination resistor ensures signal integrity at the end of the chain
-
Continuous EMI shielding provides high immunity against electrical noise
-
Rugged construction minimizes wiring errors and maintains reliable communication
-
Fully compatible with all major Series 90‑30 CPUs and remote expansion racks
-
Ideal for distributed control systems and complex automation networks
Applications
-
End-of-line expansion for remote I/O racks
-
Long-distance signal transmission in PLC systems
-
Industrial environments requiring high EMI protection
-
Distributed control and automation applications
FAQ
Q: Can the cable be installed while the system is powered?
A: No, the IC693CBL302 must be installed with the system powered off to ensure safety.
Q: Is this cable compatible with all Series 90‑30 CPUs?
A: Yes, it supports CPUs 331–341 (up to 4 expansion cables) and CPUs 350–374 (up to 7 expansion cables).
Q: Why does it include a termination resistor?
A: The built-in 100‑ohm resistor maintains proper signal integrity at the end of the I/O bus.
