Product Description
The GE Fanuc IC693ALG221 is an 8-channel analog input module engineered for the Series 90‑30 PLC platform. It converts analog signals from sensors such as temperature, pressure, or flow transmitters into precise digital values for PLC processing. Designed for versatility, the IC693ALG221 supports multiple input ranges and provides high-resolution measurement with built-in diagnostics for reliable industrial control.
This module offers hot-swappable installation in standard Series 90‑30 rack slots, allowing easy maintenance or replacement without system downtime. Its isolation between channels and the PLC logic ensures signal integrity even in electrically noisy environments, making it suitable for both factory floor and process control applications.
Technical Specifications
| Specification |
Details |
| Model |
IC693ALG221 |
| Product Type |
8-Channel Analog Input Module |
| System Compatibility |
Series 90‑30 PLC |
| Input Channels |
8 single-ended channels |
| Supported Input Ranges |
0–10 V, ±10 V, 0–20 mA, 4–20 mA |
| Resolution |
12-bit (4096 counts) |
| Accuracy |
±0.25% of full scale |
| Input Impedance |
Voltage: >100 kΩ; Current: 250 Ω |
| Update Rate |
All channels updated each PLC scan |
| Isolation |
Channel-to-PLC isolation |
| Power |
Supplied by Series 90‑30 rack power supply |
| Diagnostics |
Over-range and under-range detection, fault reporting |
| Installation |
Standard rack slot, hot-swappable |
| Weight |
0.81 lbs |
| Environmental Conditions |
0°C to 60°C operating temperature |
Key Features
-
Flexible Signal Support: Handles both voltage and current inputs, suitable for a wide range of process sensors.
-
High Precision: 12-bit resolution ensures accurate analog-to-digital conversion.
-
Integrated Diagnostics: Detects over-range or under-range conditions and reports faults to the CPU.
-
Hot-Swap Installation: Replace or service modules without interrupting PLC operation.
-
Signal Isolation: Protects the logic side of the PLC from electrical interference.
-
Easy Integration: Configurable through standard PLC programming software; no external conditioning required.
Applications
-
Process control monitoring (temperature, pressure, flow)
-
Factory automation requiring high-accuracy analog input
-
Integration with Series 90‑30 PLC I/O systems
-
Data acquisition in industrial control systems
FAQ
Q: How many channels does the IC693ALG221 support?
A: 8 single-ended analog input channels.
Q: What input ranges are compatible with this module?
A: 0–10 V, ±10 V, 0–20 mA, and 4–20 mA signals.
Q: Can it be replaced while the system is running?
A: Yes, it supports hot-swap installation.
Q: What PLC systems are supported?
A: Compatible with GE Fanuc Series 90‑30 PLC racks.
