Description
Product Overview
The GE IC660BBA024P1 Current Source I/O Block from the Series 90-30 product line delivers precise analog signal interfacing for industrial automation. It supports 24–48 VDC operation and provides 4 inputs with 2 outputs, ensuring reliable performance in process control environments.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC660BBA024P1 |
| Manufacturer |
GE |
| Module Type |
Current Source I/O Block |
| Dimensions |
9 × 11.2 × 22.4 cm |
| Weight |
1.48 kg |
| System |
DCS |
| Communication Service |
Ethernet router |
| Input Channels |
4 isolated channels |
| Output Channels |
2 isolated channels |
| Input Power Source |
24 V current loop |
| Output Current Range |
4–20 mA |
| Voltage Range |
24–48 VDC |
| Accuracy (Inputs) |
0.1% full-scale at 25°C |
| Resolution (Inputs) |
1 µA |
| Conversion Time |
16.6–400 ms |
| Accuracy (Outputs) |
0.15% full-scale |
| Resolution (Outputs) |
6 µA |
| Update Frequency |
6–8 ms |
| Circuit Isolation |
Yes |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| MOQ |
1 |
Functional Highlights
The IC660BBA024P1 supplies a 24 V current loop for each input channel and delivers 4–20 mA rated outputs. Its voltage-to-frequency converter transforms analog signals into digital values, ensuring accurate engineering unit generation. Diagnostic functions enhance monitoring and reliability.
Design and Performance
GE engineered the IC660BBA024P1 with factory calibration and isolated circuits for precision. Its compact design offers robust performance, while conversion and update times ensure fast response in automation systems.
Applications and Compatibility
The IC660BBA024P1 Current Source I/O Block suits SCADA systems, process monitoring, and industrial automation requiring accurate analog signal handling. It connects directly to 24–48 VDC bus switching modules, making it ideal for turbine control and manufacturing environments.
