Description

Overview

The IC200UEI008 is a discrete input expansion unit within the GE Fanuc Emerson VersaMax Micro platform, designed to extend digital sensing capability in compact PLC systems. It adds 8 additional 24 VDC input channels to an existing controller, enabling system scalability without redesigning the core control architecture.

This module is typically used in distributed or machine-level I/O extensions where additional field signals must be integrated while maintaining a small footprint and stable backplane communication.

Key Technical Specifications

• Manufacturer: GE Fanuc / Emerson

• Series: VersaMax Micro

• Model: IC200UEI008

• Product Type: Digital Input Expansion Module

• Input Channels: 8 points

• Mounting Method: DIN rail or panel installation

• Weight: 0.61 lb

Electrical Characteristics

• Input Voltage: 24 VDC nominal

• Input Current: up to ~20 mA per channel (typical industrial sensor load range)

• Input Signal Thresholds:

• ON state: ~15 VDC minimum

• OFF state: ≤5 VDC

• Total Input Power Consumption: ~4 W

• Sensor Supply Capability: up to 200 mA auxiliary field power

• Input Type: Compatible with dry-contact and electronic switching devices

• Logic Configuration: Supports both sourcing and sinking input configurations (system dependent)

Performance & Functional Design

• Interface: Direct backplane communication with VersaMax Micro CPU

• Signal Processing: Real-time discrete input scanning

• Hot-Swap Capability: Supported in compatible system configurations

• Expansion Limit: Up to 4 modules per PLC base unit

• Response Time: Optimized for standard industrial digital signal acquisition

• Isolation: Channel-to-backplane electrical isolation for noise immunity

Environmental Ratings

• Operating Temperature: –40°C to +70°C

• Storage Temperature: –40°C to +85°C

• Humidity: 5%–95% non-condensing

• Designed for industrial environments with vibration and electrical noise resistance

System Integration Notes

The module connects through the VersaMax Micro backplane and does not require separate programming. Configuration is handled within the PLC logic environment, where additional input points are automatically mapped into the controller’s I/O table.

Supplied or compatible connection cable: IC200CBL501 (system dependent configuration)

Typical Applications

• Machine-level signal expansion

• Conveyor and material handling systems

• Packaging line input monitoring

• Pump station status monitoring

• Building subsystem signal collection

• Retrofit upgrades for legacy control systems

FAQ

Q1: Does the IC200UEI008 provide output channels?
A1: No, it is strictly a digital input expansion module with no output functionality.

Q2: Can it be hot-swapped during operation?
A2: Yes, in supported VersaMax Micro configurations, it can be replaced without full system shutdown.

Q3: How many expansion modules can be used per PLC system?
A3: Up to four expansion modules depending on controller configuration.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
