Description

Product Description

The IC200EBI001 Ethernet Interface Unit is part of the GE Vernova VersaMax PLC ecosystem, designed to manage distributed I/O communication through industrial Ethernet networks. It operates as a networked I/O controller, enabling remote expansion racks to function as a unified control system over standard 10/100Base-T infrastructure.

This module is commonly deployed in modular automation architectures where deterministic Ethernet communication, flexible I/O scaling, and system diagnostics are required. It supports multiple industrial communication standards and integrates directly into VersaMax backplane systems for compact rack-based installation.

Core System Functions

• Ethernet-based control of VersaMax I/O stations

• Remote and distributed I/O architecture support

• Real-time industrial communication over 10/100 Mbps networks

• Integrated diagnostics and module health monitoring

• Firmware update capability via network connection

• Automatic I/O module recognition at startup

Technical Specifications

General Information

• Model: IC200EBI001

• Product Type: Ethernet Network Interface Unit (ENIU)

• PLC Platform: VersaMax Series

• Function: Remote I/O controller and Ethernet communication gateway

• Mounting Method: DIN rail or panel installation within VersaMax rack

• Weight: 0.14 kg

Network Communication

• Ethernet Interface: 1 × RJ-45 port

• Transmission Speed: 10/100 Mbps auto-negotiation

• Cabling: CAT5 or higher, twisted pair

• Maximum Cable Distance: 100 m per segment

• Supported Protocols:

• Modbus TCP

• Ethernet Global Data (EGD)

• Class 0 / Class 1 messaging

• DeviceNet (system dependent configuration)

• Duplex Mode: Full / Half duplex supported

• Web/FTP access for configuration and firmware updates

I/O Capacity & Data Handling

• Maximum Modules Supported: up to 64 modules (configuration dependent)

• Data Exchange Capacity:

• 512 bytes input data

• 512 bytes output data

• 128 bytes diagnostic/fault data

• Expansion Capability: multi-rack distributed I/O architecture

• Hot module insertion supported (firmware dependent)

Power & Backplane Requirements

• Power Source: Supplied via VersaMax backplane

• 5V Current Consumption: approx. 175 mA

• 3.3V Consumption (advanced variants): up to 425 mA

• No external field power required for ENIU operation

Environmental Conditions

• Operating Temperature: 0 °C to 40 °C (standard unit)

• Storage Temperature: 0 °C to 50 °C

• Relative Humidity: up to 80% non-condensing

• Maximum Operating Altitude: 1000 m above sea level

• Compliance: CE, UL, cUL industrial certifications

Functional Highlights

• Automatic configuration of connected I/O modules

• Continuous system diagnostics with LED status indicators (PWR, OK, FAULT, LAN, STAT)

• Remote firmware upgrade via FTP

• Stable Ethernet communication for distributed control systems

• Designed for continuous operation in industrial environments

Application Areas

• Distributed I/O systems in manufacturing lines

• Water and wastewater treatment control networks

• Energy generation and distribution monitoring

• Process automation in continuous production facilities

• Modular PLC-based control architectures

FAQ

Q: Does IC200EBI001 support Modbus TCP?
A: Yes, it supports Modbus TCP in compatible system configurations.

Q: How many I/O modules can be connected?
A: Up to 64 modules depending on rack and system configuration.

Q: Can firmware be updated remotely?
A: Yes, updates are supported via FTP over Ethernet.

Q: Is this module hot-swappable?
A: I/O modules can be hot-inserted depending on firmware version and system setup.

Specifications

• Brand: General Electric

Advantages

• High reliability in industrial environments
• Supports continuous operation
• Compatible with major PLC/DCS systems
