Description
Overview
The IC200CHS003 is a VersaMax-series connector-style I/O carrier developed by GE Fanuc Emerson. It functions as the physical and electrical interface between VersaMax I/O modules and the system backplane while also providing field wiring termination through a high-density connector layout.
This carrier is intended for single-module mounting applications where compact DIN-rail installation and structured wiring organization are required. It supports vertical module orientation and is designed for rapid replacement and simplified maintenance in modular control assemblies.
Electrical and Interface Design
The carrier integrates backplane communication pathways with external field wiring through a 36-pin connector interface. It supports both signal distribution and power/common routing for attached I/O modules.
-
36-pin field wiring connector interface
-
Supports up to 32 I/O signal points
-
Provides 4 dedicated common/power terminals
-
Backplane pass-through for module communication
-
Designed for crimp-contact wiring or pre-assembled cable harnesses
Mechanical Construction
-
DIN rail mounting compatible (35 mm standard EN 50022)
-
Snap-lock installation with conductive rail grounding support
-
Vertical module orientation for optimized rack density
-
Integrated latch mechanism for secure module retention
-
Compact single-slot footprint
Electrical Ratings
-
Current capacity per I/O point: up to 2 A
-
Common and power line capacity: up to 8 A
-
Maximum transient voltage tolerance: 300 VAC
-
Designed for low-resistance backplane connectivity
-
Optimized for short-run field wiring architectures
Wiring and Installation Method
Field wiring is terminated directly into the 36-pin connector using crimp contacts or pre-wired cable assemblies. The latch system allows quick insertion and removal of harnesses without disturbing adjacent modules.
Interposing terminal blocks may be used when additional isolation or field breakout is required.
Environmental and Handling Notes
-
Designed for conductive DIN rail grounding to improve EMC performance
-
Connector surfaces should not be handled during operation
-
Thermal rise at connector interface may occur under high load conditions
-
Suitable for compact cabinet installations with limited wiring space
System Compatibility
The IC200CHS003 is compatible with most VersaMax I/O modules. However, it is not intended for use with high-isolation or specialty modules requiring enhanced separation (such as certain high-density analog or isolated digital variants).
Applications
-
Compact distributed I/O wiring systems
-
Machine-level control cabinets
-
Modular PLC expansion racks
-
Pre-wired control panel assemblies
-
Retrofit automation cabinet upgrades
FAQ
Q1: How many I/O points can be wired through this carrier?
It supports up to 32 signal points plus 4 common/power connections.
Q2: Can it be used with all VersaMax modules?
It is compatible with most modules, but not recommended for high-isolation types requiring special separation.
Q3: What installation method is used?
It mounts directly on a standard 35 mm DIN rail with snap-lock retention.
