The IC693CPU363 is a mid-level central processing unit for the GE Fanuc Series 90-30 PLC family. Designed for medium-to-large automation applications, it integrates fast processing, generous memory, and built-in serial communication interfaces. This CPU module provides reliable execution of control logic, management of I/O, and seamless connectivity to peripheral devices.
Technical Specifications
| Feature |
Specification |
| Model |
IC693CPU363 |
| Series |
GE Fanuc Series 90-30 PLC |
| Module Type |
Single-Slot CPU Module |
| Processor Speed |
25 MHz |
| User Memory |
240 KB RAM (configurable) |
| Register Memory |
240 KB |
| I/O Capacity |
Up to 4096 discrete points across 8 racks |
| Communication Ports |
Built-in RS-232 and RS-485 serial ports, 3 total ports |
| Programming Languages |
Ladder Logic, Structured Text, and other Series 90-30 supported languages |
| Typical Scan Rate |
~0.22 ms per 1K Boolean logic contacts |
| Power Requirements |
890 mA from +5 VDC supply |
| Memory Storage Type |
RAM and Flash |
| Operating Temperature |
0–60 °C (32–140 °F) |
| Storage Temperature |
-40–85 °C (-40–185 °F) |
| Dimensions |
130 × 100 × 40 mm |
| Weight |
0.45 kg |
Key Features
-
Integrated Serial Communication: Built-in RS-232 and RS-485 ports allow direct device connections and network integration.
-
Expanded Memory: 240 KB RAM accommodates larger control programs and complex logic sequences.
-
Scalable I/O: Supports thousands of discrete points across multiple racks for flexible system design.
-
High-Speed Processing: 25 MHz CPU ensures fast, reliable scan times for real-time control.
-
Compact Form Factor: Single-slot design simplifies installation while maintaining full system functionality.
Applications
-
Manufacturing Automation: Controls assembly lines, robotic operations, and packaging systems.
-
Process Control: Manages chemical, food, and pharmaceutical processing tasks.
-
Utilities: Supports water treatment, HVAC, and energy distribution systems.
-
Material Handling: Enables distributed I/O for conveyor and warehouse automation.
FAQ
Q: What is the memory capacity of the IC693CPU363?
A: It provides 240 KB of user-configurable RAM and register memory for complex control programs.
Q: How many communication ports does it include?
A: The CPU features 3 serial ports: RS-232 and RS-485 for direct device and network communication.
Q: Can it support multi-rack systems?
A: Yes, it can handle up to 4096 discrete I/O points distributed across 8 racks.
Q: What programming languages are compatible?
A: Supports Ladder Logic, Structured Text, and other Series 90-30 languages.
