Overview
The General Electric Fanuc IC698CPE010 CPU Module powers PACSystem RX7i controllers with advanced processing and versatile connectivity. GE designed this unit to manage complex automation tasks, ensuring reliable real-time control and efficient system performance.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC698CPE010 |
| Module Type |
CPU Module |
| Manufacturer |
GE Fanuc |
| Condition |
Brand New |
| Range of Product |
Rx7i PACSystem |
| Lead Time |
In Stock |
| Weight |
0.62 kg |
| HS Code |
8537101190 |
| Dimensions |
4 × 18.3 × 29.1 cm |
| MOQ |
1 |
| Origin |
USA |
| System |
PLC |
| Status |
Active |
| Communication Service |
Ethernet Router |
Functional Description
The IC698CPE010 CPU integrates an Intel Celeron 300 MHz processor, executing Boolean logic at 0.33 ms per 1,000 contacts. Engineers equipped the module with 10 MB of battery-backed RAM and 10 MB of non-volatile memory, supporting up to 512 program blocks of 128 KB each. It handles 32Kbits of discrete I/O and 32K words of analog input and output data.
Dual Ethernet ports provide 10/100 Mbps speeds with support for EGD, SRTP, and Modbus TCP protocols. Three serial ports enable RS-232 and RS-485 communication, while Media Redundancy Protocol ensures high availability. The module supports floating-point operations, multiple programming languages, and configuration through Proficy Machine Edition software.
Applications and Compatibility
The IC698CPE010 CPU Module integrates seamlessly with GE Fanuc Rx7i PACSystem controllers. Industrial operators use this module for real-time control, data processing, and automation management. Its compact dimensions, dual Ethernet connectivity, and robust memory capacity make it suitable for manufacturing, energy distribution, and heavy-duty industrial environments.
