Description
Product Overview
The IC698CHS017 is a 17-slot rack (baseplate) designed for the PACSystems RX7i series from GE Fanuc / Emerson. It provides mechanical support and a fully integrated backplane to house CPUs, power supplies, and I/O modules. Ideal for large-scale automation systems, this rack enables high-density module installation while maintaining reliable communication and power distribution across all connected devices.
Technical Specifications
| Feature |
Specification |
| Model |
IC698CHS017 |
| Series |
PACSystems RX7i |
| Module Type |
17-Slot I/O Rack / Baseplate |
| Number of Slots |
17 slots for CPU, power supply, and I/O modules |
| Backplane Type |
Embedded bus for module communication and power distribution |
| Mounting |
Horizontal or rear rack mounting |
| Compatibility |
Supports RX7i CPUs, I/O modules, power supplies, and communication modules |
| Dimensions |
66 × 28 × 10 cm (approx. 11.2 × 19 × 7.5 inches H × W × D) |
| Weight |
7.29 kg |
| Construction |
Metal frame with plastic guides for precise module alignment |
| Power Supply |
Supports up to 350 W installed power module |
| Current Ratings |
60 A at 5 VDC, 4 A at 12 VDC |
| Cooling |
Passive; fan assembly optional |
| Operating Voltage |
5–12 VDC |
| I/O Capacity |
17 slots |
| Environmental |
Operating temp: 0–40 °C, Storage temp: 0–50 °C, Max relative humidity: 80% non-condensing |
| Maximum Operating Altitude |
1000 meters above sea level |
Key Features
-
High-Density Capacity: Accommodates 17 modules for extensive automation configurations.
-
Backplane Reliability: Ensures stable communication and power delivery between CPU, I/O, and power modules.
-
Industrial-Grade Construction: Sturdy metal frame with plastic guides for safe and accurate module placement.
-
Easy Installation: Slide-in guided slots with secure locking for quick maintenance and replacement.
-
Flexible Integration: Compatible with all RX7i series modules including CPU, I/O, power, and communication units.
Applications
-
Large-Scale Manufacturing: Houses PLC components controlling robotic systems, conveyor lines, and assembly operations.
-
Process Automation: Provides distributed I/O for chemical, food, and pharmaceutical industries.
-
Utility Automation: Supports high-density automation in power plants, water treatment, and HVAC systems.
-
Modular Expansion: Facilitates future upgrades or reconfiguration of RX7i systems with minimal downtime.
FAQ
Q: How many modules can be installed in this rack?
A: The IC698CHS017 provides 17 slots for CPUs, I/O modules, and power supplies.
Q: Does it require active cooling?
A: No, it operates with passive cooling; a fan assembly is optional if desired.
Q: Is it compatible with all RX7i modules?
A: Yes, it supports RX7i CPUs, I/O modules, power supplies, and communication modules.
Q: What mounting options are supported?
A: Horizontal or rear rack mounting for flexible system installation.
