Description
Product Overview
The IC698ACC720 is an accessory module for the PACSystems RX7i series, designed to occupy unused slots in RX7i racks. This blank module ensures mechanical protection, maintains proper airflow, and prevents accidental contact with exposed backplane connectors. Lightweight yet durable, it is ideal for maintaining system integrity and flexibility in industrial automation applications.
Technical Specifications
| Feature |
Specification |
| Model |
IC698ACC720 |
| Series |
PACSystems RX7i |
| Module Type |
Slot Filler / Blank Module |
| Function |
Covers unused slots to maintain airflow and safety |
| Rack Compatibility |
RX7i backplanes and racks |
| Construction |
Lightweight plastic/metal with integrated locking mechanism |
| Dimensions |
Standard RX7i module size (~17 × 15 × 5 cm) |
| Weight |
200 g |
| Electrical Role |
None – purely mechanical |
| Packaging |
Typically supplied in packs (e.g., 6 units) |
| Protection |
Shields backplane from dust, debris, and accidental contact |
Key Features
-
Rack Protection: Safeguards unused slots from dust, debris, and mechanical damage.
-
Airflow Management: Supports proper ventilation to maintain cooling efficiency within the rack.
-
Safety Enhancement: Covers exposed connectors to reduce risk of electrical shorts.
-
Easy Installation: Slide-in design with locking mechanism; no tools required.
-
Modular Flexibility: Keeps slots available for future module expansion without compromising protection.
Applications
-
Industrial Automation: Protects RX7i racks in factories or control panels where not all slots are used.
-
System Maintenance: Allows flexible addition of modules later while keeping unused slots secure.
-
Environmental Protection: Reduces contamination and extends rack and module life in dusty or harsh environments.
-
Packaging & Utilities: Ensures safety and cooling in systems controlling conveyors, robotics, or process automation.
FAQ
Q: Can the IC698ACC720 handle electrical signals?
A: No, it is a purely mechanical accessory for slot coverage.
Q: Is it compatible with all RX7i racks?
A: Yes, it fits all standard RX7i backplanes and module slots.
Q: How many modules come in a pack?
A: Typically supplied in packs of six.
Q: Does it require tools for installation?
A: No, the module uses a slide-in design with a simple locking mechanism.
