Product Description
The IC698ACC701 is a versatile auxiliary module for GE Fanuc RX3i and RX7i PACSystems, combining backup power, communication support, and advanced accessory functionality. It safeguards CPU memory against power loss, enables robust RS‑232/485 and Ethernet connectivity, and provides terminal expansion for analog and digital I/O. This module is engineered for reliability in harsh industrial environments, including manufacturing, process automation, and energy systems.
Depending on system integration, the IC698ACC701 may serve as a smart battery module, communication accessory, or advanced wiring accessory. All variants share a compact, durable design and compatibility with RX3i/RX7i CPUs.
Key Features
-
Auxiliary Smart Battery provides 3.6 V DC backup for CPU RAM
-
Lithium-Thionyl Chloride chemistry ensures long service life (~5 years) and up to 200 days runtime
-
Integrated 4‑pin JAE connector with adapter for seamless installation
-
Communication module supports RS‑232/RS‑485 and Ethernet interfaces
-
Rugged construction and wide temperature tolerance for industrial-grade applications
-
Advanced accessory variant enables digital and analog signal consolidation, 500 VAC isolation, and single-slot rack mounting
Technical Specifications
Electrical & Battery
-
Type: Auxiliary Smart Battery / Accessory Module
-
Voltage: 3.6 V DC
-
Capacity: 7 Ah
-
Chemistry: Lithium / Thionyl Chloride (Li‑SOCl₂)
-
Max Current: 15 A
-
Battery Life: Up to 200 days
-
Typical Service Life: ~5 years
-
Lithium Content: 5.1 g
Environmental
-
Operating Temperature: 0°C to 60°C (battery); –25°C to +70°C (communication accessory)
-
Storage Temperature: –40°C to +70°C
-
Humidity: 5%–95% non‑condensing
-
Casing: Flame-retardant ABS (battery) / Rugged metal (communication accessory)
Mechanical
-
Battery Module Dimensions: 14.5 × 6.35 × 3.8 cm
-
Weight: 0.19 lbs
-
Communication Accessory Module Dimensions: 178 × 102 × 254 mm, 1.27 kg
-
Advanced Accessory Module (RX3i) Dimensions: 44 × 132 × 310 mm, 0.4 kg
Connectivity
-
Embedded 4‑pin female JAE connector
-
Includes factory-supplied 4‑pin male to 2‑pin female adapter
-
Supports integration with RX3i/RX7i CPUs and I/O chassis
Applications
-
CPU RAM backup for RX3i/RX7i systems
-
PLC–HMI and PLC–I/O communication over RS‑232, RS‑485, and Ethernet
-
Signal consolidation and terminal expansion for digital (24 VDC) and analog (0–10 V, 4–20 mA) inputs
-
Industrial manufacturing, process control, and energy management systems
FAQ
Q: Can the IC698ACC701 replace standard RX3i battery modules?
A: Yes, the auxiliary smart battery variant provides full CPU RAM backup.
Q: Is the communication accessory compatible with Ethernet-based systems?
A: Yes, it supports RS‑232/RS‑485 and Ethernet interfaces for diagnostics and firmware updates.
Q: What environments can it operate in?
A: Battery modules operate at 0–60 °C; communication and advanced accessory variants are rated for –25–70 °C.
Q: Are adapters included for installation?
A: Yes, all variants include the necessary JAE connector adapters.
