The General Electric Fanuc IC697VAL314 Converter Board enhances Series 90-70 PLC systems with precise analog-to-digital conversion. GE designed this module with a 12-bit ADC, strong isolation, and real-time monitoring, ensuring accurate signal processing in industrial automation.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC697VAL314 |
| Module Type |
Converter Board |
| Manufacturer |
GE Fanuc |
| Condition |
Brand New |
| Range of Product |
Series 90-70 |
| Lead Time |
In Stock |
| Weight |
0.42 kg |
| HS Code |
8537101190 |
| Dimensions |
2.1 × 20.2 × 26.1 cm |
| MOQ |
1 |
| Origin |
USA |
| System |
PLC |
| Status |
Active |
| Communication Service |
Ethernet Router |
Functional Description
The IC697VAL314 Converter Board incorporates a 12-bit ADC, enabling high-resolution analog-to-digital conversion. Engineers designed the unit to scan input channels automatically once powered, eliminating the need for additional software. It supports input ranges from ±50 mV to ±10 VDC, with built-in overvoltage protection for safe operation. The module provides 1000 VDC isolation and includes a front-panel LED for real-time input monitoring.
Occupying 128 bytes of I/O VMEbus space, the IC697VAL314 board uses jumpers for flexible installation on any 128-byte boundary. Factory-configured 40 Hz input filters reduce interference, while functional categories such as Board ID register, BIT voltage reference, and analog input multiplexing improve performance. Calibration and periodic maintenance ensure long-term reliability and accuracy.
Applications and Compatibility
The IC697VAL314 Converter Board integrates seamlessly with GE Fanuc Series 90-70 PLC systems. Industrial operators use this module for signal conversion, monitoring, and automation control. Its compact dimensions, strong isolation, and LED diagnostics make it suitable for manufacturing, energy distribution, and heavy-duty industrial environments.
