Description
Product Description
The IC697PWR713 is a high-performance power supply module for the GE Fanuc Series 90-70 PLC system. It converts AC input into regulated DC voltages, supplying stable power to the PLC backplane and all installed modules. Designed for demanding industrial environments, this module supports large PLC configurations, ensures reliable operation under heavy loads, and incorporates comprehensive protection features.
Technical Specifications
| Specification |
Details |
| Model |
IC697PWR713 |
| Product Type |
Power Supply Module |
| Series |
Series 90-70 PLC |
| Input Voltage |
90–264 VAC (auto-ranging), 100–150 VDC |
| Frequency |
47–63 Hz |
| Output Voltages |
+5 VDC, +12 VDC, -12 VDC |
| Output Current |
+5 VDC up to 50 A; ±12 VDC up to 3 A |
| Output Power |
100 W maximum across all outputs |
| Power Factor |
>0.93 |
| Cooling |
Forced air with internal fan |
| Protection |
Overvoltage, overcurrent, and thermal safeguards |
| Indicators |
LED status for power and fault conditions |
| Mounting |
Fits Series 90-70 PLC rack power supply slot |
| Operating Temperature |
0°C to +60°C |
| Storage Temperature |
-40°C to +85°C |
| Dimensions |
200 × 80 × 40 mm |
| Weight |
1.81 kg |
Key Features
-
High current output supports extensive PLC systems with multiple modules.
-
Provides multiple regulated voltages: +5 VDC for logic circuits and ±12 VDC for analog and communication devices.
-
Built-in protection against overload, overvoltage, and excessive temperature.
-
Internal fan ensures consistent cooling under continuous heavy operation.
-
LED indicators provide visual confirmation of power status and faults.
-
Compact form factor for easy integration into 90-70 PLC racks.
Applications
-
Powering CPU, I/O, and communication modules in large-scale PLC racks.
-
Industrial process control systems, manufacturing plants, and energy management applications.
-
Environments requiring robust, continuous, and regulated DC power supply for PLC operation.
FAQ
Q: What AC input range does IC697PWR713 support?
A: It supports 90–264 VAC or 100–150 VDC input.
Q: What are the output voltages and capacities?
A: +5 VDC up to 50 A, ±12 VDC up to 3 A.
Q: Does it have protection features?
A: Yes, it includes overvoltage, overcurrent, and thermal protection.
Q: Can it operate in high-temperature environments?
A: It operates reliably from 0°C to +60°C and can be stored from -40°C to +85°C.
Q: What are typical use cases?
A: Large industrial automation systems requiring stable and high-capacity DC power.
