Description
Overview
The General Electric Fanuc IC697PWR710 Power Supply Module energizes Series 90-70 PLC systems with stable backplane power. GE designed this converter board to deliver efficient energy distribution, advanced protection, and reliable operation under varying industrial conditions.
Technical Specifications
| Parameter |
Value |
| Model Number |
IC697PWR710 |
| Module Type |
Converter Board |
| Manufacturer |
GE Fanuc |
| Condition |
Brand New |
| Range of Product |
Series 90-70 |
| Lead Time |
In Stock |
| Weight |
1.02 kg |
| HS Code |
8537101190 |
| Dimensions |
6.5 × 21.8 × 29.3 cm |
| MOQ |
1 |
| Origin |
USA |
| System |
PLC |
| Status |
Active |
| Communication Service |
Ethernet Router |
Functional Description
The IC697PWR710 module supports input ranges of 90–264 VAC at 47–63 Hz or 100–150 VDC. It delivers a nominal output of 5.1 VDC, adjustable between 4.90 and 5.25 VDC, with a maximum output of 56 Watts. Engineers equipped the unit with overvoltage protection clamping at 6.2 Volts and overcurrent limiting at 12 Amperes. A 21 ms ride-through time ensures stability during short AC interruptions. The module incorporates active power factor correction above 0.95, reducing circuit breaker oversizing. Noise immunity and a dedicated ground terminal enhance reliability, while installation in the leftmost rack slot provides configuration flexibility.
Applications and Compatibility
The IC697PWR710 Power Supply Module integrates seamlessly with GE Fanuc Series 90-70 PLC systems. Industrial operators use this module for automation, energy distribution, and machine control. Its compact dimensions, protective features, and efficient power factor correction make it suitable for manufacturing, energy conversion, and heavy-duty industrial environments.
