Product Description
The IC697MDL654 is a high-density discrete output module designed for the GE Fanuc Series 90-70 PLC platform. It provides reliable DC output points capable of driving solenoids, relays, lamps, and other field devices in industrial and process control applications.
This single-slot module delivers 32 positive logic outputs with a nominal voltage of 24 VDC, supporting up to 0.5 A per point and a maximum total module current of 16 A. Outputs are opto-isolated to ensure immunity against electrical noise, and the module is organized into four isolated groups of 8 points each for safe and flexible wiring. Two 20-pin connectors facilitate field connections, while LED indicators provide visual status for operational monitoring.
Designed for industrial reliability, the IC697MDL654 supports continuous operation under harsh conditions and is compatible with proximity switches, positive/negative logic devices, and standard Series 90-70 racks.
Technical Specifications
| Feature |
Specification |
| Model |
IC697MDL654 |
| Manufacturer |
GE Fanuc / Emerson |
| Series |
Series 90-70 PLC |
| Module Type |
Discrete Output Module |
| Output Voltage |
24 VDC nominal (operational 33–56 VDC) |
| Number of Outputs |
32 discrete points |
| Logic Type |
Positive/Negative logic compatible |
| Output Current |
0.5 A per point, 16 A max per module |
| Isolation |
Opto-isolated outputs, 1500 VDC isolation voltage |
| Field Connections |
2 × 20-pin connectors |
| Slot Requirement |
Single-slot module |
| Operating Temperature |
0°C to +60°C |
| Weight |
3.00 lbs |
| Module Groups |
Four isolated groups of 8 points each |
| Compatible Devices |
Solenoids, relays, lamps, proximity switches |
| Dimensions |
Standard Series 90-70 rack size |
Key Features & Benefits
High-Density Outputs: 32 points maximize rack efficiency for large I/O systems.
Industrial Reliability: Rugged design ensures dependable operation in demanding environments.
Opto-Isolated Protection: Noise immunity for stable output performance.
Flexible Integration: Compatible with a wide range of DC field devices.
Compact Design: Single-slot form factor fits directly into Series 90-70 racks.
Applications
-
Driving solenoids, relays, and DC actuators
-
Machine control and process automation
-
Integration with proximity switches and indicator lamps
-
Medium-to-large PLC I/O expansion
FAQ
Q: Which PLC series is IC697MDL654 compatible with?
A: Exclusively designed for GE Fanuc Series 90-70 PLCs.
Q: What is the maximum output per point?
A: Each output supports up to 0.5 A, with 16 A maximum for the entire module.
Q: Is the module noise-protected?
A: Yes, outputs are opto-isolated for electrical noise immunity.
Q: How are outputs organized?
A: Outputs are arranged in four isolated groups of 8 points each for flexible wiring.
