Product Description
The IC697CPX928 is a robust CPU module engineered for the GE Fanuc Series 90-70 PLC family. Designed for large-scale and mission-critical automation systems, this module combines advanced processing power with high memory capacity to support complex control applications and extensive I/O configurations.
Equipped with a 32-bit microprocessor running at 96 MHz and 6 MB of RAM, the IC697CPX928 can manage up to 12,000 I/O points, including 8,000 analog points. It offers multiple communication options, including one RS-232 and two RS-485 serial ports, along with a dedicated factory reset port. Flash memory of 256 KB stores firmware and user programs, while the optional IC697ACC701 lithium battery preserves critical system data.
This single-slot CPU module features high-speed Boolean scan rates (0.4 µs per function) and supports ladder logic, structured text, and advanced GE Fanuc programming software. It operates reliably from 0°C to +60°C and fits standard Series 90-70 racks, making it an ideal choice for complex industrial automation projects.
Technical Specifications
| Feature |
Specification |
| Model |
IC697CPX928 |
| Manufacturer |
GE Fanuc / Emerson |
| Module Type |
CPU Module |
| PLC Series |
Series 90-70 |
| Microprocessor |
80486DX4, 32-bit floating point |
| Clock Speed |
96 MHz |
| RAM |
6 MB for user logic and data |
| Flash Memory |
256 KB |
| I/O Capacity |
Up to 12K points (8K analog I/O) |
| Communication Ports |
1 × RS-232, 2 × RS-485, 1 × Factory Reset |
| Battery Support |
IC697ACC701 lithium battery |
| Slot Requirement |
Single-slot module |
| Scan Rate |
0.4 µs per Boolean function |
| Operating Temperature |
0°C to +60°C |
| Weight |
1.83 lbs |
Key Features & Benefits
High-Speed Processing: 96 MHz CPU supports complex control and high I/O throughput.
Large Memory Capacity: 6 MB RAM plus 256 KB flash memory ensures extensive program and data storage.
Extensive I/O Handling: Supports up to 12,000 I/O points for multi-rack systems.
Versatile Communication: Serial ports allow connection to remote racks, HMIs, and expansion modules.
Reliable Design: Operates continuously in demanding industrial environments.
Applications
-
Large-scale PLC systems and distributed control networks
-
Process control requiring high-speed logic and floating-point calculations
-
Multi-rack automation configurations with extensive I/O
-
Critical systems where reliability and uptime are essential
FAQ
Q: Can this CPU module be used in Series 90-30 PLCs?
A: No, the IC697CPX928 is compatible only with Series 90-70 PLC systems.
Q: What is the maximum I/O capacity?
A: Supports up to 12,000 total I/O points, including 8,000 analog points.
Q: Which programming languages are supported?
A: Ladder Logic, Structured Text, and advanced GE Fanuc software programming.
Q: Is a battery required?
A: Optional IC697ACC701 lithium battery is recommended to retain critical data during power loss.
