The IC697CPX772 from GE Fanuc is a high-performance CPU module designed for Series 90-70 PLC systems. Powered by a 96 MHz 80486DX4 processor, it delivers fast execution and supports up to 2,000 discrete I/O points and 8,000 analog words.
This module includes 512KB RAM and 256KB flash memory, ensuring reliable data handling. The IC697CPX772 features three serial ports—RS232 via RJ11 and RS485 via 15-pin D-shell connectors—with optocoupler isolation on Port 2 for enhanced signal integrity.
Technical Specifications
| Specification |
Details |
| Model Number |
IC697CPX772 |
| Module Type |
Digital I/O CPU Module |
| Manufacturer |
General Electric (GE) |
| Series |
Series 90-70 |
| System |
PLC |
| Dimensions |
4 × 21.8 × 29.3 cm |
| Weight |
0.62 kg |
| Processor |
80486DX4, 96 MHz |
| Memory |
512KB RAM, 256KB Flash |
| I/O Capacity |
2,000 Discrete, 8,000 Analog |
| Serial Ports |
RS232 (RJ11), RS485 (2×D-shell) |
| Protocols |
SNP, SNPX, RTU |
| Execution Speed |
0.4 µs per Boolean instruction |
| RTC Accuracy |
±3.5 sec/day |
| Elapsed Time Accuracy |
±0.1% |
| Battery Type |
IC697ACC701 (Lithium) |
| Battery Life |
5 Years Shelf, 6 Months Retention |
| Current Draw |
3.1 A |
| Operating Temp |
0°C to 60°C |
| LED Indicators |
7 (OK, RUN, Memory Protection) |
| Mode Switch |
3-Position |
| Communication |
Ethernet Router |
| HS Code |
8537101190 |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Status |
Active |
Features & Performance
-
The IC697CPX772 supports floating-point calculations for precision control tasks.
-
Its real-time clock ensures accurate timekeeping for automation processes.
-
The onboard battery preserves memory during power interruptions.
-
Seven LED indicators provide clear system status feedback during operation.
Applications & Compatibility
The IC697CPX772 integrates seamlessly into GE Fanuc Series 90-70 PLC architectures. It suits industrial automation tasks requiring high-speed logic execution, serial device integration, and reliable memory retention.
Compatible with programming terminals and serial peripherals, the IC697CPX772 offers flexible control for manufacturing, energy, and process industries.
