Description
Product Overview
The IC697CPU782 Floating Point CPU from GE Fanuc’s Series 90-70 PLC family delivers high-speed processing for demanding automation tasks. Powered by a 16 MHz 80386DX microprocessor, it executes Boolean logic at 0.4 microseconds per function. This module supports floating point calculations, PID control, and advanced comparisons, making it ideal for precision control systems.
With 512 KB of expansion memory and support for 12 KB discrete and 8 KB analog I/O, the IC697CPU782 handles large-scale industrial applications. It connects via serial, parallel, or Ethernet interfaces and integrates with VME C.1 standard backplanes. A key switch protects memory from unauthorized changes, while a lithium battery ensures RAM retention for up to six months.
Technical Specifications
| Specification |
Details |
| Model Number |
IC697CPU782 |
| Module Type |
Floating Point CPU |
| Product Series |
Series 90-70 |
| Manufacturer |
GE Fanuc |
| Dimensions |
4 × 21.8 × 29.3 cm |
| Weight |
0.62 kg |
| Processor |
80386DX @ 16 MHz |
| Execution Speed |
0.4 µs Boolean logic |
| Discrete I/O Capacity |
12 KB |
| Analog I/O Capacity |
8 KB |
| Expansion Memory |
512 KB |
| Programming Software |
Logicmaster, VersaPro, Proficy |
| Programming Interfaces |
Serial, Parallel, Ethernet |
| Memory Protection |
Key switch |
| Battery Backup |
IC697ACC701 (6 months retention) |
| Vibration Resistance |
1 G |
| Shock Resistance |
15 G |
| Operating Temperature |
0°C to 60°C |
| Storage Temperature |
-40°C to 85°C |
| Rack Compatibility |
5-slot or 9-slot (slot 1 CPU) |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC697CPU782 supports floating point operations and PID control for precision automation.
-
Its 80386DX processor delivers fast logic execution and reliable performance.
-
Expansion memory allows storage of complex programs and large datasets.
-
Key switch and lithium battery protect and retain memory during power loss.
-
Compatible with multiple programming platforms and communication interfaces.
