Product Description
The IC697CPU771 is a robust central processing unit module for the GE Fanuc Series 90-70 PLC family. Designed to provide reliable processing, memory management, and communication capabilities, it is ideal for medium-to-large automation systems that demand stable and consistent performance.
Equipped with an Intel 80386 (or 80C816DX) microprocessor, the IC697CPU771 operates at 12–20 MHz, delivering fast execution of ladder logic and advanced control programs. It supports up to 512 KB of battery-backed RAM for user programs and data storage, along with discrete and analog I/O memory for efficient system operation.
The module includes built-in serial communication ports (RS-232/RS-485) for integration with supervisory systems, remote I/O, or other PLC modules. Its single-slot form factor fits standard Series 90-70 racks, with LED indicators for module status, RUN, and output enable, ensuring clear operational feedback.
Technical Specifications
| Feature |
Specification |
| Model |
IC697CPU771 |
| Manufacturer |
GE Fanuc / Emerson |
| Series |
Series 90-70 PLC |
| Module Type |
CPU Module |
| Processor |
Intel 80386 / 80C816DX, 12–20 MHz |
| Memory |
512 KB RAM (expandable, battery-backed) |
| Discrete I/O Memory |
2 KB |
| Analog I/O Memory |
8 KB |
| Boolean Execution Speed |
0.4 µs per function |
| I/O Capacity |
Up to 2000 mixed I/O points per module |
| Communication Ports |
RS-232, RS-485 serial interface |
| Slot Requirement |
Single-slot CPU module |
| Power Backup |
Lithium battery (IC697ACC701) for memory retention |
| LED Indicators |
Module OK, RUN, Outputs Enabled |
| Operating Temperature |
0°C to +60°C |
| Dimensions |
Standard Series 90-70 rack size |
| Weight |
1 lb |
Key Features & Benefits
Reliable Processing: Fast CPU execution supports medium-to-large automation programs.
Expandable Memory: 512 KB RAM with battery backup ensures user logic and data are preserved.
Communication Ready: Built-in serial ports facilitate connection to supervisory systems and remote I/O.
High I/O Support: Handles thousands of discrete and analog I/O points across multiple racks.
Industrial Durability: Rugged design ensures long-term operation in demanding environments.
Applications
-
Machine control in manufacturing lines
-
Process control in chemical, food, or packaging industries
-
Integration in multi-rack Series 90-70 PLC systems
-
Remote I/O and supervisory system interfacing
FAQ
Q: Which PLC series is IC697CPU771 compatible with?
A: It is compatible exclusively with GE Fanuc Series 90-70 PLCs.
Q: What is the maximum user program memory?
A: Up to 512 KB of battery-backed RAM.
Q: Does it include communication ports?
A: Yes, it has RS-232 and RS-485 serial interfaces for PLC network integration.
Q: Can it execute floating-point math operations?
A: Yes, floating-point operations are fully supported.
