Description
Product Overview
The IC697CPU711 Central Processing Unit from GE Fanuc’s Series 90-70 PLC family delivers reliable logic execution for industrial automation. Powered by an 80C186 microprocessor running at 12 MHz, it processes Boolean instructions at 0.4 microseconds per function. This module supports both discrete and analog I/O configurations and integrates seamlessly with GE’s rack-mounted VME C.1 standard backplane.
With support for up to 512 KB of expansion memory, the IC697CPU711 handles complex control programs and large datasets. It includes a 15-pin D-type serial port for RS-232, RS-422, or RS-485 communication. Password-controlled access ensures secure program management, while compatibility with Logicmaster 90-70, VersaPro, and Proficy software simplifies development.
Technical Specifications
| Specification |
Details |
| Model Number |
IC697CPU711 |
| Module Type |
Central Processing Unit |
| Product Series |
Series 90-70 |
| Manufacturer |
GE Fanuc |
| Dimensions |
4 × 21.8 × 29.1 cm |
| Weight |
0.5 kg |
| Processor |
80C186 @ 12 MHz |
| Execution Speed |
0.4 µs Boolean logic |
| Discrete I/O Capacity |
2 KB |
| Analog I/O Capacity |
8 KB |
| Expansion Memory |
Up to 512 KB |
| Programming Software |
Logicmaster, VersaPro, Proficy |
| Communication Interface |
15-pin D-type serial port |
| Protocol Support |
RS-232, RS-422, RS-485 |
| Memory Security |
Password-protected access |
| Backplane Format |
VME C.1 Standard |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC697CPU711 executes logic quickly with a 12 MHz processor and 0.4 µs instruction speed.
-
It supports 2 KB discrete and 8 KB analog I/O for flexible control setups.
-
Expansion memory up to 512 KB allows for large program storage.
-
Serial communication supports RS-232, RS-422, and RS-485 protocols.
-
Password protection secures programming access and system integrity.
