Description
Product Overview
The IC697CPM925 is a high-performance central processing unit for the GE Fanuc Series 90-70 PLC platform. Engineered for large-scale automation systems, this CPU module delivers fast logic execution, extensive memory for complex programs, and multiple communication options. Its design supports continuous operation in demanding industrial environments while allowing scalable I/O expansion.
Technical Specifications
| Feature |
Specification |
| Model |
IC697CPM925 |
| Series |
GE Fanuc Series 90-70 PLC |
| Module Type |
Single-Slot CPU Module |
| Processor Speed |
25 MHz (64-bit floating-point capable) |
| User Memory |
1 MB RAM for program and data storage |
| I/O Capacity |
Supports up to 12,000 discrete I/O points across multiple racks |
| Communication Ports |
Built-in RS-232 and RS-485; expandable via Genius Bus or Ethernet modules |
| Programming Languages |
Ladder Logic, Structured Text, and other Series 90-70 compatible languages |
| Typical Scan Rate |
0.2 ms per 1K Boolean logic contacts |
| Dimensions |
130 × 100 × 40 mm |
| Weight |
0.5 kg |
| Operating Environment |
0–60 °C, continuous operation |
| Storage Temperature |
-40–85 °C |
| Reliability |
Designed for high-duty industrial applications |
Key Features
-
High Memory Capacity: 1 MB RAM enables complex logic programs and large-scale process management.
-
Efficient Processing: 25 MHz CPU ensures rapid execution of control routines, suitable for multi-rack systems.
-
Versatile Communication: Built-in serial ports and optional Genius Bus or Ethernet modules provide network flexibility.
-
Scalable I/O Support: Handles extensive discrete and analog I/O across multiple racks for large automation setups.
-
Industrial Reliability: Rugged design ensures consistent performance under continuous operation.
Applications
-
Manufacturing Automation: Control of large assembly lines, robotic cells, and automated packaging systems.
-
Process Control: Monitoring and regulation of chemical, food, and pharmaceutical processing operations.
-
Utilities: Power generation, water treatment, and HVAC systems integration.
-
Material Handling: Distributed I/O management for conveyors and automated warehouses.
FAQ
Q: What is the memory specification of the IC697CPM925?
A: The module features 1 MB of RAM, suitable for complex logic programs and large-scale applications.
Q: Which communication interfaces are included?
A: Built-in RS-232 and RS-485 ports; support for Genius Bus or Ethernet modules is available.
Q: How many I/O points can this CPU manage?
A: It supports up to 12,000 discrete I/O points across multiple racks.
Q: What programming languages are supported?
A: Compatible with Ladder Logic, Structured Text, and all Series 90-70 supported languages.
