Description
Product Overview
The IC697CMM742 Ethernet Interface Module from GE Fanuc’s Series 90-70 PLC family enables robust network communication for industrial automation. It supports multiple physical interfaces including RS-232, RS-485, AUI, 10BaseT, and 10Base2, allowing flexible integration with SCADA, HMI, and control systems.
This module facilitates data exchange using Ethernet Global Data (EGD) and SRTP protocols. It includes LED indicators for Module OK, LAN Online, Serial Active, and Status OK, plus a restart button for quick reinitialization. A replaceable fuse protects the AUI transceiver port, and the unit operates reliably between 0°C and 55°C.
Technical Specifications
| Specification |
Details |
| Model Number |
IC697CMM742 |
| Module Type |
Ethernet Interface Module |
| Product Series |
Series 90-70 |
| Manufacturer |
GE Fanuc |
| Dimensions |
4 × 21.8 × 29.1 cm |
| Weight |
0.8 kg |
| Serial Ports |
RS-232, RS-485 |
| Network Ports |
AUI, 10BaseT, 10Base2 |
| Protocols Supported |
EGD, SRTP |
| Diagnostic Indicators |
4 LEDs (status monitoring) |
| Restart Function |
Manual reset button |
| Fuse Protection |
Replaceable AUI fuse |
| Operating Temperature |
0°C to 55°C |
| Module Capacity |
Up to 4 per CPU rack |
| Compliance |
CE, UL/CUL 508 |
| HS Code |
8537101190 |
| Condition |
Brand New |
| Origin |
USA |
| System Compatibility |
PLC |
| Discontinued Status |
Active |
| Minimum Order Quantity |
1 |
| Lead Time |
In Stock |
Features & Benefits
-
The IC697CMM742 supports multiple Ethernet and serial interfaces for flexible device connectivity.
-
It enables real-time data exchange using EGD and SRTP protocols.
-
LED indicators and a restart button simplify diagnostics and recovery.
-
AUI port includes fuse protection for added reliability in harsh environments.
-
Up to four modules can operate simultaneously in one Series 90-70 CPU rack.
