Description
Product Description
The IC697CHS770 is a robust 9-slot rack designed for the GE Fanuc Series 90-70 PLC family. It serves as the central housing for CPUs, power supplies, I/O, and communication modules, providing both mechanical support and high-speed electrical interconnection.
This chassis features a rugged aluminum construction, suitable for harsh industrial environments, and accommodates up to two complete PLC systems per rack. The backplane ensures reliable, high-speed communication between installed modules, while the design allows flexible panel or cabinet mounting. Its 9-slot configuration supports scalable system architectures, making it ideal for medium to large automation applications.
Technical Specifications
| Feature |
Specification |
| Model |
IC697CHS770 |
| Manufacturer |
GE Fanuc / Emerson |
| Series |
Series 90-70 PLC |
| Module Type |
Rack / Chassis |
| Number of Slots |
9 slots |
| Supported Modules |
CPU, I/O, communication, specialty modules |
| Backplane |
High-speed interconnection bus for module communication |
| Power Supply |
Compatible with Series 90-70 power supply modules |
| Construction |
Rugged aluminum chassis |
| Mounting Options |
Panel or cabinet mounting |
| Operating Temperature |
0°C to +60°C |
| Dimensions |
Standard Series 90-70 rack size, ~19-inch width |
| Weight |
20 lbs |
Key Features & Benefits
Scalable Configuration: 9 slots accommodate CPU, I/O, and communication modules.
Reliable Backplane: High-speed interconnection ensures stable communication between modules.
Industrial Durability: Aluminum chassis provides rugged protection for long-term operation.
Flexible Installation: Suitable for both panel and cabinet mounting.
High System Capacity: Supports multiple racks and large automation projects.
Applications
-
Central housing for Series 90-70 PLC modules
-
Medium-to-large industrial process control systems
-
Machine control and automation system expansion
-
High-reliability environments requiring multiple PLC systems
FAQ
Q: How many slots does the IC697CHS770 provide?
A: The chassis includes 9 module slots for CPU, I/O, and communication modules.
Q: Can it host multiple PLC systems?
A: Yes, it can support up to 2 complete PLC systems per rack.
Q: What mounting options are available?
A: Suitable for both panel and cabinet installations.
Q: Is it compatible with all Series 90-70 modules?
A: Yes, it supports CPU, I/O, communication, and specialty modules designed for Series 90-70.
