Product Description
The IC697BEM742 is a precision bus expansion module for the GE Fanuc Series 90-70 PLC family, designed to extend the backplane and support additional PLC racks. By enabling communication between the main CPU and expansion racks, this module allows larger and more complex automation systems to be implemented without compromising signal integrity.
Equipped with dual FIP bus connectors and a serial interface, the IC697BEM742 ensures high-speed, reliable data transfer while providing electrical isolation to minimize noise and interference. The module operates at 5 VDC, consumes 1.3 A on the backplane, and features six LED indicators for status monitoring. Its single-slot design and standard Series 90-70 dimensions make installation simple and space-efficient.
Ideal for process control, large-scale industrial automation, and distributed I/O systems, this module is typically available new or refurbished with standard supplier warranties.
Technical Specifications
| Feature |
Specification |
| Model |
IC697BEM742 |
| Manufacturer |
GE Fanuc |
| Module Type |
Bus Expansion / FIP Bus Controller |
| PLC Series |
Series 90-70 |
| Function |
Expands CPU backplane to connect additional racks |
| Slots Required |
Single-slot module |
| Operating Voltage |
5 VDC |
| Backplane Current |
1.3 A |
| Connectors |
Dual 9-pin FIP Bus, 15-pin serial |
| LED Indicators |
6 LEDs for operational status |
| Isolation |
Electrical isolation between racks for noise immunity |
| Operating Temperature |
0°C to +60°C |
| Dimensions |
Standard Series 90-70 rack size |
| Weight |
1.25 lbs |
Key Features & Benefits
Seamless System Expansion: Connect additional racks to existing Series 90-70 PLCs.
Reliable Communication: Maintains high-speed data transfer across expansion racks.
Noise Protection: Electrical isolation prevents interference in demanding environments.
Compact Design: Single-slot module saves space within the PLC rack.
Durable Construction: Engineered for continuous operation in industrial settings.
Applications
-
Extending PLC backplanes to add extra racks
-
Distributed control systems with multiple I/O locations
-
Large-scale automation requiring reliable data transfer
-
Industrial process monitoring and control networks
FAQ
Q: Can this module be used with Series 90-30 PLCs?
A: No, the IC697BEM742 is compatible only with Series 90-70 PLCs.
Q: How many expansion racks can be supported?
A: The number depends on rack configuration and system backplane limits; consult system manuals for maximum expansion.
Q: What communication protocols are supported?
A: Supports FIP bus and serial communication for Series 90-70 expansion racks.
Q: Is electrical isolation provided?
A: Yes, the module isolates racks to minimize noise and signal interference.
