Description
Product Overview
The IC697BEM713 Bus Transmitter Module by GE Fanuc expands Series 90-70 PLC systems by linking up to seven IC697BEM711 Bus Receiver Modules. It supports daisy-chain configurations with a maximum cable length of 50 feet and requires a terminating resistor (IC697ACC702) at the final receiver for stable communication.
This module occupies one chassis slot (excluding slot 1) and draws 1.4A at 3.3V DC. It supports a data rate of 500 Kbytes/sec and stores a 16KB program in 20–30 seconds. The IC697BEM713 includes a parallel programming port and an expansion port for connecting receiver modules. It complies with ME standard C.1 and works with expansion cables like IC600WD005A, IC600WD010A, IC600WD025A, and IC600WD050A.
Technical Specifications
| Parameter |
Specification |
| Model Number |
IC697BEM713 |
| Manufacturer |
GE Fanuc |
| Module Type |
Bus Transmitter Module |
| Product Series |
Series 90-70 |
| Input Voltage |
3.3V DC |
| Current Draw |
1.4A |
| Data Rate |
500 Kbytes/sec |
| Program Storage Time |
20–30 sec for 16KB |
| Expansion Support |
Up to 7 Bus Receiver Modules |
| Cable Compatibility |
IC600WD005A/010A/025A/050A |
| LED Indicators |
Power-up, Bus Status, Programmer Comm |
| Dimensions |
4 x 22 x 29.1 cm |
| Weight |
0.46 kg |
| System Compatibility |
PLC, Series 90-70 |
| HS Code |
8537101190 |
| Origin |
USA |
| Condition |
Brand New |
| Availability |
In Stock |
Features
-
Enables scalable expansion of Series 90-70 PLC systems.
-
Supports parallel programming and modular connectivity.
-
Provides visual diagnostics via three LED indicators.
-
Operates with multiple cable lengths up to 50 feet.
-
Ensures reliable communication with terminating resistor.
