Description
Overview
The IC697ALG321 analog input module from GE Fanuc delivers high-precision signal conversion for Series 90-30 PLC systems. It supports both unipolar and bipolar voltage ranges, making it suitable for diverse industrial monitoring tasks.
This module features a 12-bit converter and stores data in 2’s complement format. The IC697ALG321 provides configurable alarm thresholds and fast input filtering, ensuring accurate and responsive analog-to-digital conversion.
Technical Specifications
| Specification |
Details |
| Model Number |
IC697ALG321 |
| Module Type |
Analog Input Module |
| Manufacturer |
General Electric (GE) |
| Series |
Series 90-30 |
| System |
PLC |
| Dimensions |
4 × 22 × 29.1 cm |
| Weight |
0.42 kg |
| Input Type |
Unipolar / Bipolar Voltage |
| Resolution |
12-bit ADC, 16-bit word storage |
| Filter Frequency |
41 Hz (Single-Ended), 82 Hz (Differential) |
| Alarm Settings |
High/Low Voltage Thresholds |
| Configuration |
MS-DOS / Logicmaster Software |
| Memory Format |
2’s Complement |
| Data Storage |
EEPROM in PLC CPU |
| Communication |
Ethernet Router |
| HS Code |
8537101190 |
| Lead Time |
In Stock |
| Minimum Order |
1 Unit |
| Origin |
USA |
| Status |
Active |
Features & Performance
-
The IC697ALG321 supports flexible voltage input ranges for analog signal acquisition.
-
Its 12-bit resolution ensures accurate data capture and conversion.
-
Input filtering enhances signal integrity in noisy environments.
-
Configuration is simple using Logicmaster or MS-DOS-based tools.
Applications & Compatibility
The IC697ALG321 integrates seamlessly into GE Fanuc Series 90-30 PLC systems. It suits applications requiring precise analog input monitoring, including temperature sensors, pressure transducers, and voltage feedback loops.
Compatible with both handheld programmers and software-based tools, the IC697ALG321 enhances analog signal processing in industrial automation.
