Description
Product Description
The IC697ACC722 is a high-density I/O terminal block designed for the GE Fanuc Series 90-70 PLC system, providing a secure interface between field devices and PLC modules. With 48 screw-type terminals, this module simplifies wiring, ensures vibration-resistant connections, and organizes multiple discrete and analog signals in a compact footprint.
Engineered for industrial-grade reliability, the IC697ACC722 supports standard wiring sizes, offers electrical isolation between field wiring and the PLC backplane, and allows easy installation directly onto 90-70 I/O modules. This accessory is ideal for large-scale automation systems, process control, and manufacturing environments where efficient and maintainable wiring is critical.
Technical Specifications
| Specification |
Details |
| Model |
IC697ACC722 |
| Product Type |
I/O Terminal Block (Accessory) |
| Series |
Series 90-70 PLC |
| Terminal Type |
Screw-type connections |
| Number of Terminals |
48 connection points |
| Mounting |
Direct attachment to Series 90-70 I/O modules |
| Wiring Capacity |
Standard industrial wiring sizes supported |
| Isolation |
Provides electrical isolation from PLC backplane |
| Dimensions |
Compact for rack installation |
| Compatibility |
Works with GE Fanuc 90-70 PLC I/O modules |
| Durability |
Industrial-grade construction for long-term reliability |
| Weight |
0.44 lbs |
| Slot Restrictions |
Cannot be installed in Slot 1 of any rack; compatible with Slots 2–8 in 9-slot racks and 2–4 in 5-slot racks |
Key Features
-
High-density wiring: 48 terminals provide a compact and organized connection interface.
-
Secure screw terminals: Reliable and vibration-resistant connections for field devices.
-
Simplified maintenance: Structured wiring reduces troubleshooting time.
-
Electrical isolation: Protects PLC backplane from voltage spikes and interference.
-
Industrial durability: Built to withstand harsh automation environments.
Applications
-
Organizing discrete and analog signal wiring for Series 90-70 PLC systems.
-
Manufacturing plants requiring multiple field device connections.
-
Process industries and energy systems with high wiring density needs.
-
Any automation system requiring reliable and maintainable I/O connections.
FAQ
Q: How many connection points does IC697ACC722 provide?
A: 48 screw-type terminals.
Q: Can it handle both analog and discrete signals?
A: Yes, it is compatible with both types of field wiring.
Q: Which slots in the rack are compatible for installation?
A: Slots 2–8 in 9-slot racks and 2–4 in 5-slot racks; slot 1 is not supported.
Q: Does it provide isolation between field wiring and PLC backplane?
A: Yes, electrical isolation is built into the design.
